Summary of Contents for AIC RSC-2KT

  • Page 1 RSC-2KT Rackmount Storage Chassis User's Manual UM_RSC-2KT_v1_092419...
  • Page 2: Table Of Contents

    Table of Contents Preface ������������������������������������������������������������������������������������������������� i Safety Instructions ������������������������������������������������������������������������������ ii About This Manual ������������������������������������������������������������������������������ iv Chapter 1� Product Features �������������������������������������������������������������� 1 1.1 Components ..................... 1 1.2 Specifications ..................2 1.3 Feature ..................... 2 Chapter 2� Hardware Setup ���������������������������������������������������������������� 5 2.1 Top Cover ....................5 2.2 Power Supply Unit Module ..............
  • Page 3 Document Release History Release Date Version Update Content September User's Manual release to public. 2019 Content...
  • Page 4 Copyright © 2019 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.
  • Page 5: Preface

    Disclaimer AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...
  • Page 6: Safety Instructions

    Safety Instructions Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components. •...
  • Page 7 • If one of the following situations arise, the equipment should be checked by service personnel: 1. The power cord or plug is damaged. 2. Liquid has penetrated the equipment. 3. The equipment has been exposed to moisture. 4. The equipment does not work well or will not work according to its user manual. 5.
  • Page 8: About This Manual

    LED descriptions. Chapter 4 Technical Support For more information or suggestion, please contact the nearest AIC corporation representative in your district or visit the AIC website: http://www.aicipc.com/en. It is our greatest honor to provide the best service for our customers.
  • Page 9: Chapter 1� Product Features

    Chapter 1. Product Features RSC-2KT User Manual Chapter 1. Product Features RSC-2KT is a flexible rackmount storage chassis with tool-less design. This product supports hot swapple HDDs and easy swap fans. For more information about our product, please visit our website at http://www.aicipc.com/en.
  • Page 10: 1.2 Specifications

    RSC-2KT User Manual Chapter 1. Product Features 1.2 Specifications mm : 430 x 680 x 88 2 x 4-port 12Gb SATA/SAS backplanes with Dimensions Backplane SFF-8643 connector (W x D x H) inches : 17 x 26.8 x 3.5 Storage 0ºC(32ºF) ~ 50ºC(122ºF)
  • Page 11 RSC-2KT User Manual Chapter 1. Product Features Front Panel USB 3.0 Port 8 x 3.5-inch drive bays Power Button System Power LED System HDD Activity LED LAN LED System Alert LED System ID LED System ID Button System Reset Button...
  • Page 12 RSC-2KT User Manual Chapter 1. Product Features Top View 3 x 80x25mm PWM easy swap fans 4 x 2.5-inch disk drive (BTO)
  • Page 13: Chapter 2� Hardware Setup

    Chapter 2� Hardware Setup RSC-2KT User Manual Chapter 2. Hardware Setup 2�1 Top Cover  Simultaneously press the release button on both sides of the chassis and push the cover toward the rear panel.  Lift the top cover to complete removal.
  • Page 14: Power Supply Unit Module

    Chapter 2. Hardware Setup RSC-2KT User Manual 2�2 Power Supply Unit Module  Extract the power supply unit by synchronously pressing the release button and pulling the power supply unit out of the chassis.  Pull the module completely out of the chassis.
  • Page 15: Fan Module

    RSC-2KT User Manual Chapter 2. Hardware Setup 2�3 Fan Module  Unplug the all of the cables and connectors.  Lift the fan module upward. Check to carefully dislodge the rubber connectors from the attached bracket.  Insert the new fan into the chassis. Verify to align the rubber connectors with the appropriate slot in the bracket.
  • Page 16: Hard Disk Drive

    Chapter 2. Hardware Setup RSC-2KT User Manual 2�4 Hard Disk Drive 2�4�1 Drive: 3�5-inch  Press the release button to release the tray lever.  Pull the tray lever outward completely.  Pull the tray out of the chassis.  Remove tray.
  • Page 17: Drive: 2.5-Inch

    RSC-2KT User Manual Chapter 2. Hardware Setup 2�4�2 Drive: 2�5-inch  Remove the top cover from the chassis. Please refer to 2.5 Top Cover.  Lift the disk drive from the bracket holder.  Match the dimples on the bracket holder and insert the new disk drive into the...
  • Page 18: Hdd Backplane Module

    Chapter 2. Hardware Setup RSC-2KT User Manual 2�5 HDD Backplane Module  Detach the cables and hard disk drives from the backplane module.  Dislodge the screws on the backplane bracket.  Lift the bracket out of the chassis.  Dissemble the bracket from the backplane to complete removal.
  • Page 19: Slide Rail Installation

    RSC-2KT User Manual Chapter 2. Hardware Setup 2�6 Slide Rail Installation NOTE This sections provides a basic instruction for mounting the slide rail onto the system. Tool-less rails vary per order. The rail in this manaul may not exactly match the rail for your system.
  • Page 20 Chapter 2. Hardware Setup RSC-2KT User Manual  Install the inner rail onto the system barebone. Lock the keyholes and secure the screws. Keyhole screw  Continue installing the outer rail bracket to the mounting frame. Attach the outer rail assembling to the frame and press the bracket to fix the rail onto the frame.
  • Page 21 RSC-2KT User Manual Chapter 2. Hardware Setup  Pull out the middle channel until the ball bearing retainer is locked forward. NOTE Verify ball bearing retainer is locked forward.  Slide the release tab and push barebone into rack. Make sure the barebone is...
  • Page 22: Chapter 3. Hardware Specifications

    Chapter 3. Hardware Specifications RSC-2KT User Manual Chapter 3. Hardware Specification 3�1 HDD Backplane 3�1�1 Placement Top view JPWR2 JPWR1 SASHD JSGPIO_SET CPLD Bottom view HDD1 HDD2 HDD3 HDD4 3�1�2 Connector and Jumper Power Connector (JPWR1 & JPWR2) SGPIO Function and setting...
  • Page 23: Led Indicator

    RSC-2KT User Manual Chapter 3. Hardware Specification 3�1�3 LED Indicator Blue (On) HDD is present. HDD Activity LED Blue (Blinking) HDD activity is detected or HDD is located. HDD is not connected or the power is off. Off Red (On) HDD fault occurred or HDD is located.
  • Page 24: Chapter 4� Technical Support

    Chapter 4� Technical Support Taiwain, Global Headquarters South California, United States Address: No� 152, Section 4, Address: 21808 Garcia Lane Linghang N� Rd, Dayuan District, City of Industry, CA 91789, Taoyuan City 337, Taiwan United States Tel: +886-3-433-9188 Toll free: +7-4997019998 Fax: +886-3-287-1818 Tel: +1-909-895-8989 Fax: +1-909-895-8989#157...
