Summary of Contents for Clarke CEP1

  • Page 1 ELECTRIC PLANER ELECTRIC PLANER MODEL No. CEP1 Part No. 6462025 OPERATING & MAINTENANCE INSTRUCTIONS 0305...
  • Page 2: Specifications

    Thank you for purchasing this CLARKE Electric Planer which is designed for DIY and light workshop use only. Before attempting to use the machine, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to the planer giving you long and satisfactory service.
  • Page 3: Safety Precautions

    Safety Precautions WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. 1.
  • Page 4 14. ALWAYS wear proper apparel. loose clothing or jewellery may get caught in moving parts. wear protective hair covering to contain long hair. 15. ALWAYS use recommended accessories. the use of improper accessories could be hazardous. 16. ALWAYS remove plug from electrical outlet when adjusting, changing parts, or working on the machine.
  • Page 5: Electrical Connections

    (as indicated by marking or colour code). 4. Replacement fuse covers can be obtained from your local Clarke dealer or most electrical stockists. FUSE RATING The fuse in the plug must be replaced with one of the same rating (5 amps) and this replacement must be ASTA approved to BS1362.
  • Page 6 Operation 1. Ensure machine is switched OFF and isolated from the mains supply. 2. Ensure workbench etc. is on a firm flat foundation, and workpiece is clamped securely to the bench. 3. Adjust the cutting depth required with adjusting knob (see fig. 1), turn knob Trigger clockwise from 0mm to 2mm.
  • Page 7 Blade Replacement Note : Blade Cylinder Item numbers refer to parts list, page 11 To replace blades proceed as follows : Ensure Planer is switched off and isolated from the electrical supply, by removing the plug from the socket. Turn depth adjusting knob fully clockwise to position ‘2’.
  • Page 8: Trouble Shooting

    Excessive sparking occurs This indicates worn brushes. This problem is quickly remedied but you should consult your CLARKE dealer for parts and advice. Planer does not operate when switched ON Check to ensure the fuse is sound and replace if necessary. If the fuse is sound or blows repeatedly, consult your CLARKE dealer.
  • Page 9 HAND-ARM VIBRATION Employers are advised to refer to the HSE publication “Guide for Employers”. All hand held power tools vibrate to some extent, and this vibration is transmitted to the operator via the handle, or hand used to steady the tool. Vibration from about 2 to 1500 herz is potentially damaging and is most hazardous in the range from about 5 to 20 herz.
  • Page 10: Parts List

    Parts List Item Part No Description Qty Item Part No Description GRCEP1001 Namplate GRCEP1026 Armature GRCEP1002 S.T Screw GRCEP1027 Wind Loop GRCEP1003 Cover GRCEP1028 Ball Bearing GRCEP1004 Brush Holder GRCEP1029 Drum GRCEP1005 Brush GRCEP1030 Blade GRCEP1006 Switch GRCEP1031 Screw GRCEP1007 Capacitor GRCEP1032 Blade Guide...
  • Page 11 Parts Diagram Accessories A wide range of accessories is available from your nearest CLARKE dealer, for further information, contact your nearest dealer, or telephone CLARKE International Sales department on 01992 565300. - 10 -...
