6 inch PLANER
6 inch PLANER
Part No. 6460200
MODEL Nos. CP-6
Part No. 6462125
OPERATING & MAINTENANCE
INSTRUCTIONS
©
0906

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke CP-6

  • Page 1 6 inch PLANER 6 inch PLANER Part No. 6460200 MODEL Nos. CP-6 Part No. 6462125 OPERATING & MAINTENANCE INSTRUCTIONS © 0906...
  • Page 2: Specifications

    Dimensions ................. 693x323x345mm Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machines data bracket...
  • Page 3: Table Of Contents

    Please read these instructions carefully before operating the tool Thank you for purchasing this CLARKE 6” Planer, designed for DIY use. Before using the device, please read this manual thoroughly and carefully follow all instructions given. This is for your own safety and that of others around you, and is also to help you achieve a long and trouble free service from your new tool.
  • Page 4: Safety Precautions

    General Safety Precautions WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. ALWAYS Learn the machines’...
  • Page 5: Signed

    14. ALWAYS wear proper apparel. Loose clothing or jewellery may get caught in moving parts. Wear protective hair covering to contain long hair. 15. ALWAYS use recommended accessories, the use of improper accessories could be hazardous. 16. ALWAYS remove plug from electrical outlet when adjusting, changing parts, or working on the machine.
  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS Connect the mains lead to a domestic, 230 volt (50Hz) electrical supply through a fused good quality 13 amp BS 1363 plug, or a suitable fused isolator switch. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Green &...
  • Page 7: Unpacking And Parts Id

    UNPACKING and PARTS IDENTIFICATION Carefully unpack the components and lay them out, checking against the following list. Should any part be missing or damaged in transit, please contact your Clarke dealer immediately. Fig. 1 A - Planer B - Fence complete...
  • Page 8: Operation

    Fig. 3 1. Attaching the Angle Fence The peg - ‘A’ locates in the slotted hole - ‘B’. It may be necessary to screw the peg down a little in order for the peg to locate properly. The Hex. socket head screw with washers (in the bag of loose parts), is used to secure the fence to the table, through slot ‘C’, into threaded hole ‘D’.
  • Page 9 2. Ensure the fence is at the correct angle - for normal planing, this would be 90 degrees. For other angles, use a template or angle gauge for greater accuracy. 3. Slide the cutter guard out of the way and place the workpiece on the table so that it rests snugly against the fence, with the lead edge a short distance from the cutter, noting that direction of feed is right to left, looking from the front of the machine.
  • Page 10: Maintenance

    Blades must always be fitted as a pair, and must be of the same type, only fit blades recommended by the Clarke International. First, ensure the machine is switched OFF and isolated from the mains supply.
  • Page 11: Parts List And Diagrams

    PARTS LIST DIAGRAM PARTS & SERVICE TEL: 020 8988 7400 e-mail as follows: PARTS: Parts@clarkeinternational.com SERVICE: Service@clarkeinternational.com IMPORTANT: The use of parts other than CLARKE replacement parts may result in safety hazards, decreased tool performance and may invalidate your warranty.
  • Page 12 SPARE PARTS DIAGRAM...
  • Page 13 PARTS LIST No. Description Qty Part No. No. Description Qty Part No. 1 Bolt NXCP6001 35 Support, right NXCP6035 2 Washer NXCP6002 36 Bolt NXCP6036 3 Stowage Bracket NXCP6003 37 Washer NXCP6037 4 Bolt NXCP6004 38 Side Cover, right NXCP6038 5 Lock Washer NXCP6005 39 Bolt...
  • Page 14 cont. No. Description Qty Part No. No. Description Qty Part No. 72 Bolt NXCP6072 105 Screw NXCP6105 73 Lock Washer NXCP6073 106 Switch NXCP6106 74 Washer NXCP6074 107 Screw NXCP6107 75 Screw NXCP6075 108 Screw NXCP6108 76 Bearing Cap NXCP6076 109 Switch Box NXCP6109 77 Needle Bearing...
