PLANER/THICKNESSER
PLANER/THICKNESSER
Part No. 6460200
MODEL Nos. CPT600 and CPT800
Part No. 6462130 and 6462135
OPERATING & MAINTENANCE
INSTRUCTIONS
0706
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPT600 and is the answer not in the manual?

Questions and answers

Related Manuals for Clarke CPT600

Summary of Contents for Clarke CPT600

  • Page 1 PLANER/THICKNESSER PLANER/THICKNESSER Part No. 6460200 MODEL Nos. CPT600 and CPT800 Part No. 6462130 and 6462135 OPERATING & MAINTENANCE INSTRUCTIONS 0706...

  • Page 2: Specifications

    Dimensions LxWxH ..........693x437x357mm ..770x449x405mm Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machines data bracket...

  • Page 3: Table Of Contents

    Please read these instructions carefully before operating the tool Thank you for purchasing this CLARKE Planer/Thicknesser designed for DIY use. Before using the device, please read this manual thoroughly and carefully follow all instructions given. This is for your own safety and that of others around you, and is also to help you achieve a long and trouble free service from your new tool.

  • Page 4: General Safety Precautions

    General Safety Precautions WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. ALWAYS Learn the machines’...

  • Page 5: Additional Precautions For Planer/Thicknessers

    14. ALWAYS wear proper apparel. Loose clothing or jewellery may get caught in moving parts. Wear protective hair covering to contain long hair. 15. ALWAYS use recommended accessories, the use of improper accessories could be hazardous. 16. ALWAYS remove plug from electrical outlet when adjusting, changing parts, or working on the machine.

  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS Connect the mains lead to a domestic, 230 volt (50Hz) electrical supply through a fused good quality 13 amp BS 1363 plug, or a suitable fused isolator switch. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Green &...

  • Page 7: Assembly

    UNPACKING and PARTS IDENTIFICATION Carefully unpack the components and lay them out, checking against the following list. Should any part be missing or damaged in transit, please contact your Clarke dealer immediately. Fig. 1 NOTE: Dust extraction devices available from...
  • Page 8 Fig. 3 1. Attaching the Angle Fence The peg - ‘A’ locates in the slotted hole - ‘B’. It may be necessary to screw the peg down a little in order for the peg to locate properly. The Hex. socket head screw with washers (in the bag of loose parts), is used to secure the fence to the table, through slot ‘C’, into threaded hole ‘D’.

  • Page 9: Operation

    Fig. 7 B. For Thicknessing B.1 Remove the Angle Fence. B.2 Push the Cutter Guard out of its holder so that the Chute may be attached to the table, as shown in Fig.7. Ensure both Locking keys are pushed firmly into the slots in the table, shown in Fig.6.
  • Page 10 Fig. 9 IMPORTANT. When coming to the end of a piece, ALWAYS use the push stick to finish - see Fig.8. This is an important safety point. To switch OFF, simply press the red button marked ‘O’ and close the cover ensuring it is properly latched.

  • Page 11: Maintenance

    Blades must always be fitted as a pair, and must be of the same type, only fit blades recommended by the Clarke International. First, ensure the machine is switched OFF and isolated from the mains supply.
  • Page 12 5. Replace in reverse order, and, using a straight edge, ensure the cutting edges are level and in line with the table when they are at 12 o’clock - see Fig.10. Tighten the securing screws taking care not to over-tighten or damage the hex.

  • Page 13: Drive Belt Replacement

    Drive Belt Replacement. Fig. 11 Remove the front cover - 3 nuts. Remove the worn or broken drive belt. Fig. 12 Place the replacement drive belt over the small belt wheel. Position part of the drive belt over the large belt wheel as shown in fig Fig.

  • Page 15: Parts Diagrams And Lists

    CPT600 Exploded Diagram & Parts List...
  • Page 16 SPARE PARTS DIAGRAM - CPT600...
  • Page 17 PARTS LIST No. Description Qty Part No. No. Description Qty Part No. Bolt NXCPT6001 Cable Clamp NXCPT6042 Cord Stowage Bkt NXCPT6002 Rubber Buffer NXCPT6043 Flat Belt NXCPT6044 Side Cover NXCPT6003 Bolt NXCPT6004 Washer NXCPT6045 Locking Washer NXCPT6005 Locking Washer NXCPT6046 Bolt NXCPT6047 Rubber Foot...
  • Page 18 No. Description Qty Part No. No. Description Qty Part No. Bolt NXCPT6078 Stud Bolt NXCPT6125 Locking Washer NXCPT6079 Cover NXCPT6126 Washer NXCPT6080 Square Tube NXCPT6127 Chain Wheel NXCPT608/1 127A Cover NXCPT6127A Chain NXCPT6082 Washer NXCPT6128 Small Belt Wheel NXCPT6083 128A Locking Ring NXCPT6128A Bolt NXCPT6084...
  • Page 19 CPT800 Exploded Diagram & Parts List...
  • Page 20 SPARE PARTS DIAGRAM - CPT800...
  • Page 21 PARTS LIST - CPT800 No. Description Qty Part No. No. Description Qty Part No. Bolt NXCPT8001 Cable Clamp NXCPT8042 Cord Stowage Bkt NXCPT8002 Rubber Buffer NXCPT8043 Side Plate Top NXCPT8003 Flat Belt NXCPT8044 Bolt NXCPT8004 Washer NXCPT8045 Locking Washer NXCPT8005 Locking Washer NXCPT8046 Rubber Buffer...
  • Page 22 No. Description Part No. No. Description Qty Part No. Cover NXCPT8126 Locking Washer NXCPT8079 Washer NXCPT8080 Square Tube NXCPT8127 Chain Wheel NXCPT8081 127A Cover NXCPT8127A Washer NXCPT8128 Chain NXCPT8082 Small Belt Wheel NXCPT8083 128A Locking Ring NXCPT8128A Bolt NXCPT8084 128B Locking Ring NXCPT8128B Hand Knob NXCPT8129...

  • Page 23: Parts And Service Contacts

    IMPORTANT: The use of parts other than CLARKE replacement parts may result in safety hazards, decreased tool performance and may invalidate your warranty. PARTS & SERVICE CONTACTS For Spare Parts and Service, please contact your nearest dealer, or CLARKE International, on one of the following numbers.
