Texas Instruments CC400DK User Manual

Texas Instruments CC400DK User Manual

Development kit
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
Rev. 1.5
CC400DK Development Kit

Advertisement

loading
Need help?

Need help?

Do you have a question about the CC400DK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Texas Instruments CC400DK

Summary of Contents for Texas Instruments CC400DK

  • Page 1 User Manual Rev. 1.5 CC400DK Development Kit...

  • Page 2: Table Of Contents

    ESCRIPTION ................9 AYOUT SKETCHES AND CIRCUIT DRAWINGS ......................... 15 ILL OF MATERIALS USING THE DEVELOPMENT KIT..................19 APPENDIX A........................... 20 LNA/PA .......... 20 INE TUNING PROCEDURE OF MATCHING NETWORK CC400DK Development kit (rev. 1.5) 2002-09-17 Page 2 of 22...

  • Page 3: Introduction

    Studio software please refer to the SmartRF Studio user manual. ® Your SmartRF CC400DK Development Kit should contain the following items: Evaluation circuit boards (PCB) 2 ex CC400 single chip transceiver 5 ex PC parallel port extension cable 2 ex...

  • Page 4: Description

    If you want to measure the DC current, replace the jumper with an amperemeter (as shown in the figure below). The current range is from 0 to 70 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 4 of 22...
  • Page 5 External IF filter The evaluation board is equipped with an external 455kHz ceramic filter. Input and output impedance to the CC400 is 1.5kΩ, and the bandwidth is approximately 30kHz. CC400DK Development kit (rev. 1.5) 2002-09-17 Page 5 of 22...
  • Page 6 Minor tuning of the component values may be necessary to compensate for layout parasitics at other frequencies or other layouts. See appendix A. CC400DK Development kit (rev. 1.5) 2002-09-17 Page 6 of 22...
  • Page 7 There are three preselector filter options: LC-filter, SAW filter, or no filter used. Each of the three filter alternatives is equipped with a female SMA antenna connector. To choose between the three filters there is a zero ohm resistor that can be moved (R61-R63). CC400DK Development kit (rev. 1.5) 2002-09-17 Page 7 of 22...
  • Page 8 Note: Using the SAW filter, the output power amplifier class should be A or AB and the output power should not exceed 0 dBm. This will give approximately –5 dBm at the antenna output. Using power settings above 0 dBm may cause stability problems. CC400DK Development kit (rev. 1.5) 2002-09-17 Page 8 of 22...

  • Page 9: Layout Sketches And Circuit Drawings

    Layout sketches and circuit drawings (No filter) (LC filter) (SAW filter) 4-10V 4-10V Module slot Switch I_out (future use) I_in 25 pin D-SUB CC400DK Development kit (rev. 1.5) 2002-09-17 Page 9 of 22...
  • Page 10 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 10 of 22...
  • Page 11 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 11 of 22...
  • Page 12 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 12 of 22...
  • Page 13 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 13 of 22...
  • Page 14 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 14 of 22...

  • Page 15: Bill Of Materials

    C_1N0_0603_NP0_J_50 C211 Capacitor 0805 33nF C_33N_0805_X7R_J_50 C231 Capacitor 0603 Do Not Mount CT152 Trimmer Capacitor C_3-10P_TRIM_NP0 Varactor diode KV1832C, Toko Ceramic filter, 455kHz CFUCG455D, Murata SAW filter, 433.92MHz B3550, Siemens CC400DK Development kit (rev. 1.5) 2002-09-17 Page 15 of 22...
  • Page 16 Value Part Capacitor, tantal C_3U3_TAN_B 3.3µF Capacitor, tantal C_3U3_TAN_B 3.3µF Capacitor 0805 33nF C_33N_0805_X7R_J_50 Diode, Si BAT254 MOSFET, P ch. SI9424DY, Siliconix SPDT switch SWITCH_SPDT Voltage regulator LP2981, 3V, National CC400DK Development kit (rev. 1.5) 2002-09-17 Page 16 of 22...
  • Page 17 R_10K_0603_G 10kΩ Resistor 0603 R_10K_0603_G 10kΩ Resistor 0603 R_100K_0603_G 100kΩ Resistor 0603 R_100K_0603_G 100kΩ Resistor 0603 R_100K_0603_G 100kΩ Resistor 0603 R_100K_0603_G 100kΩ Hex inverter, oc 74HC05 Hex inverter, oc 74HC05 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 17 of 22...
  • Page 18 D-Sub, 25 pin DSUB_25 5 pin terminal, screw SCREW_TERM_5 SMA connector (Straight) SMA connector (Straight) SMA connector (Straight) SMA connector SMA_RA (Right angle) Edge connector, 2 x 8 pin EDGE_CONN_2X8 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 18 of 22...

  • Page 19: Using The Development Kit

    The transmitted signal can be studied on a spectrum analyser, sent out on the antenna (see note below) or sent to the receiver via a cable with an attenuator attached. Antenna 4-10V Circuit board Spectrum analyser Function generator Figure: Equipment set-up in transmit mode. CC400DK Development kit (rev. 1.5) 2002-09-17 Page 19 of 22...

  • Page 20: Fine Tuning Procedure Of Lna/Pa Matching Network

    Follow the procedure below to fine-tune the matching network. Use the components that the software program calculates as initial values. Set the bits F5:F3 = 000 in the Register configuration window and update the device. 1) Receiver tuning CC400DK Development kit (rev. 1.5) 2002-09-17 Page 20 of 22...
  • Page 21 Set bit F2 to 0 and increase bits F5 to F3 by an amount following the formula below and update the device. ⎛ − ⎞ ⎜ ⎜ ⎟ ⎟ round ⎝ ⎠ Choose the value of C61 that you got from the TX tuning (C61 CC400DK Development kit (rev. 1.5) 2002-09-17 Page 21 of 22...
  • Page 22 Chipcon's RF technology ® platform with RF library cells, modules and design expertise. Based on SmartRF Chipcon develops standard component RF-circuits as well as full custom ASICs based on customers' requirements. CC400DK Development kit (rev. 1.5) 2002-09-17 Page 22 of 22...
