Summary of Contents for Ultra electronics HyperSpike MA-1 Series
- Page 1 INSTALLATION AND MOUNTING MANUAL ® HyperSpike MA-1 and MA-2 REV A Copyright © Ultra Electronics – USSI Columbia City, IN 46725 USA PART NO.: xxxxxxxxx...
- Page 3 ® HyperSpike MA-1 and MA-2 Installation and Mounting Manual This manual contains information that is proprietary to Ultra Electronics – USSI. It is intended solely for the education and use of parties operating and maintaining the equipment described herein. Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA...
-
Page 4: Color Code
90105A – MA-1 Single-Channel 90223A – MA-1 Multi-Channel 90162A – MA-1 Connectorized 90080A – MA-2 Single-Channel 90224A – MA-2 Multi-Channel 90163A – MA-2 Connectorized Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA Page 1 98028A-MAN-MASERIES Rev B... - Page 5 CAUTION: EXCEEDING THE MAXIMUM RATINGS OF THE SPEAKER WILL CAUSE EXCESSIVE DISTORTION AND MAY CAUSE PERMANENT DAMAGE TO THE SPEAKER AND ITS INTERNAL COMPONENTS. Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA Page 2 98028A-MAN-MASERIES Rev B...
- Page 6 1) To mount the MA-1/MA-2, slide the mount on the emitter head over a 2” OD pipe (not included). Figure 1: Location of the 2” ID mount Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA Page 3 98028A-MAN-MASERIES Rev B...
-
Page 7: Field Wiring
Route the conduit to a junction box approved by local electrical codes and standards. Follow your integrator’s instructions for installing into an appropriate junction system. Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA Page 4 98028A-MAN-MASERIES Rev B... - Page 8 See section 3.2.2 below for the pinout of the connector. The mating cable is sold separately. Figure 4: Connector Location Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA Page 5 98028A-MAN-MASERIES Rev B...
- Page 9 300 watts. These leads may be attached to a customer-supplied ® amplifier or the optional HyperSpike amplifier kit. Figure 5: MA-1 Single-Channel Figure 6: MA-2 Double-Channel Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA Page 6 98028A-MAN-MASERIES Rev B...
- Page 10 Pin A – Channel 1 (-) Pin B – Channel 1 (+) Pin C – Channel 2 (-) (MA-2 only) Pin D – Channel 2 (+) (MA-2 only) Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA Page 7 98028A-MAN-MASERIES Rev B...
-
Page 11: Warranty
MA-1 and MA-2 Installation and Mounting Manual 4.0 WARRANTY Ultra Electronics – USSI warrants its products to be free from defects in material and workmanship for a period of one (1) year from the date of shipment from USSI’s facility. This warranty is extended to the original purchaser and all subsequent owners, provided a copy of the original dated bill of sale is presented when service is requested under warranty. - Page 12 Ultra Electronics – USSI 4868 East Park 30 Drive Columbia City, IN 46725 USA +1-260-248-3666...
