INSTALLATION AND MOUNTING MANUAL
®
HyperSpike
TCPA-10
Copyright © Ultra Electronics – USSI Columbia City, IN 46725 USA
REV A
PART NO.: xxxxxxxxx

Advertisement

loading
Need help?

Need help?

Do you have a question about the HyperSpike TCPA-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ultra electronics HyperSpike TCPA-10

  • Page 1 INSTALLATION AND MOUNTING MANUAL ® HyperSpike TCPA-10 Copyright © Ultra Electronics – USSI Columbia City, IN 46725 USA REV A PART NO.: xxxxxxxxx...
  • Page 2 HyperSpike ® TCPA-10 Installation and Mounting Manual This manual contains information that is proprietary to Ultra Electronics – USSI. It is intended solely for the education and use of parties operating and maintaining the equipment described herein. ISSUE DATE: 10/16/2017 ORIGINAL ISSUE DATE RELATED TO MOUNTING AND WIRING DIAGRAM ONLY.
  • Page 3 Directionality: See Figure 1 Weight: 9 lb Dimensions: 10.1” H X 10.1” W X 11.3” L Suitable for Outdoor Use (Adapté à l'utilisation externe) Page 1 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 4 Max Supervisory Voltage: 50 VDC Weight: 9 lb Dimensions: 10.1” H X 10.1” W X 11.3” L Suitable for Outdoor Use (Adapté à l'utilisation externe) Page 2 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 5 DU HAUT-PARLEUR ENTRAÎNERA UNE DISTORSION EXCESSIVE ET PEUT PROVOQUER DES DOMMAGES IRRÉVERSIBLES SUR LE HAUT-PARLEUR ET SES COMPOSANTS INTERNES. Figure 1: Dispersion Characteristics at 3 meters as measured by UL Labs Page 2 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 6 DESCRIPTION 72377B-801 WALL MOUNT BRACKET DUAL UNIT MOUNTING 72378B-801 ADAPTER POLE MOUNT ADAPTER 72379B-801 AMPLIFIER KIT 90172A-807 (Direct Drive) Figure 2: Optional Accessory Kits Page 3 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 7 (¼ Trade Size Conduit has a nominal Ø.39” ID / Ø.57” OD). Mounting Bracket ¼ Trade Size Conduit Figure 3: Mounting Bracket Page 4 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 8 Figure 4: Attaching Wall Mounting Bracket 2) Attach the mounting bracket to the wall or pole with appropriate hardware according to local codes and safety practices. Page 5 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 9 2) Attach the wall mount bracket to the middle holes of the dual mount plate with three ¼-20 bolts (Figure 6). Figure 6: Attaching Dual Speaker System to a Wall Mounting Bracket Page 6 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 10 1) A tether cable may be attached to all speakers by looping the cable through the large hole in the TCPA-10 mounting bracket (Figure 7). Figure 7: Tether Attachment Point Page 7 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 11 AVERTISSEMENT : APRÈS L'INSTALLATION, VÉRIFIEZ QUE LE SPL À LA DISTANCE D'ÉCOUTE MINIMALE DE 3,3 MÈTRES (10 PIEDS) EST INFÉRIEUR À 120 DÉCIBELS (A). Page 8 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 12: Field Wiring

    (i.e. multiple TCPA-10s on the same Distributed Audio line). Direct Drive Distributed Audio Direct Drive Figure 9: TCPA-10 Wiring Diagrams Page 9 Copyright © Ultra Electronics – USSI, Columbia City, IN 46725 USA 98030A-MAN-TCPA10 Rev C...
  • Page 13: Warranty

    TCPA-10 Installation and Mounting Manual 5.0 WARRANTY Ultra Electronics – USSI warrants its products to be free from defects in material and workmanship for a period of one (1) year from the date of shipment from USSI’s facility. This warranty is extended to the original purchaser and all subsequent owners, provided a copy of the original dated bill of sale is presented when service is requested under warranty.
