Summary of Contents for Ultra electronics HyperSpike AHDi
- Page 1 OPERATION AND MAINTENANCE MANUAL AHDi...
-
Page 2: Table Of Contents
3.2. Limitation of Implied Warranties ................9 3.3. Exclusion of Certain Damages .................. 9 This manual contains information that is proprietary to Ultra Electronics - USSI. It is intended solely for the education and use of parties operating and maintaining the equipment described herein. -
Page 3: Operations
6) Turn the VOLUME control up to the desired level by turning the knob clockwise. The Control Module is now ready to transmit recorded or live voice messages. Figure 1.1-1: AHDi Control Module Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi... -
Page 4: Hyperspike ® Operating Modes
To increase the volume of the message, turn the VOLUME knob clockwise. CAUTION: Audio feedback may occur when using a live microphone, resulting in equipment damage. Always operate the microphone directly behind the AHDi Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi... -
Page 5: Selecting The Alert Tone
100 – 240 VAC. The AHDi battery pack will automatically begin charging. The charger is equipped with an LED charging indicator. Figure 1.7-2 provides guidance on the charging status of the AHDi battery pack. Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi... - Page 6 LED COLOR STATUS FAST CHARGING GREEN FULL/TRICKLE CHARGING GREEN WITH FLASHING ORANGE TOP-OFF CHARGING ALTERNATING GREEN ERROR ORANGE BATTERY PACK NOT CONNECTED Figure 1.7-2 Battery Charging Status Indicator Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi...
-
Page 7: Loading Pre-Recorded Messages
5) Double left-click on the SD card icon to open window. 6) Left-click on the START icon again and then left-click on COMPUTER. 7) Locate the custom message where it was stored. Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi... - Page 8 10) Insert SD card back into the card holder in the control module. Figure 1.8-3 shows the proper orientation of the SD card. 11) Replace cover and re-insert screws. Hand-tighten screws. Figure 1.8-2 SD Memory Card Figure 1.8-3 SD Card Orientation Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi...
-
Page 9: Troubleshooting
Section 1.8. 5) If the pre-recorded message still is not emitted from the AHDi, the unit is not functioning and needs repair. See Section 3.0 for service information. Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi... -
Page 10: Noise From Speaker
Noise coming from the speaker generally indicates that the batteries need to be re-charged. Connect the battery charger and ensure the batteries are completely charged. See Section 1.7 for battery charging instructions. Copyright © Ultra Electronics USSI Columbia City, IN 46725 USA REV B 90134A-MAN-AHDi... -
Page 11: Warranty
(1) year from the date of shipment from Ultra Electronics USSI. 3.3. Exclusion of Certain Damages Ultra Electronics USSI’s liability is limited to the repair or replacement, at our option, of any defective product, and shall in no event include incidentally or consequential commercial damages of any kind. - Page 12 Ultra Electronics USSI 4868 East Park 30 Drive Columbia City, IN 46725 USA +1-260-248-3666...
