  • Page 1 Dell EMC PowerEdge C6420 Regulatory Model: E43S Series Regulatory Type: E43S001...
  • Page 2 Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

  • Page 3: Table Of Contents

    Contents 1 PowerEdge C6420 overview.......................... 4 2 Technical specifications..........................5 Dimensions of the PowerEdge C6420 sled........................5 Chassis weight..................................6 Processor specifications..............................6 System battery................................... 6 Expansion bus specifications............................6 Memory specifications..............................6 Video specifications................................7 Environmental specifications............................7 Temperature specifications............................7 Relative humidity specifications..........................

  • Page 4: Poweredge C6420 Overview

    PowerEdge C6420 overview The PowerEdge C6420 sled supports up to two Intel Xeon Scalable E5- 2600 or E5- 2600 Fabric product family processors with 28 cores per processor. The sled also supports 16 memory modules, dedicated mezzanine, PCIe and Open Compute Project (OCP) adapters for expansion and connectivity.

  • Page 5: Technical Specifications

    • Video specifications • Environmental specifications Dimensions of the PowerEdge C6420 sled Figure 1. Dimensions of the PowerEdge C6420 sled Table 1. Dimensions of the PowerEdge C6420 sled 17.44 mm (6.86 inches) 4.05 mm (1.59 inches) 57.45 mm (22.61 inches)

  • Page 6: Chassis Weight

    No backplane systems 34.56 Kg (76.19 lb) Processor specifications The PowerEdge C6420 sled supports up to two Intel Xeon Processor Scalable Family processor in each of the four independent sleds. Each processor supports up to 28 cores. NOTE: The fabric processor must be installed in the CPU2 socket in a mixed configuration of fabric and non-fabric processors.

  • Page 7: Video Specifications

    1024 GB with dual memory optimized processor processor operation Video specifications The PowerEdge C6420 sled supports a Matrox G200 integrated graphics card with 16 MB RAM. Table 5. Supported video resolution options Resolution Refresh rate (Hz) Color depth (bits) 1024 x 768...

  • Page 8: Relative Humidity Specifications

    Relative humidity specifications Table 7. Relative humidity specifications Relative humidity Specifications Storage 5% to 95% RH with 33°C (91°F) maximum dew point. Atmosphere must be non-condensing at all times. Operating 10% to 80% relative humidity with 29°C (84.2°F) Maximum vibration specifications Table 8.

  • Page 9: Operating Temperature De-Rating Specifications

    Operating temperature de-rating specifications Table 11. Operating temperature Operating temperature de-rating Specifications Up to 35°C (95°F) Maximum temperature is reduced by 1°C/300 m (1°F/547 ft) above 950 m (3,117 ft). 35°C to 40°C (95°F to 104°F) Maximum temperature is reduced by 1°C/175 m (1°F/319 ft) above 950 m (3,117 ft).

  • Page 10: Standard Operating Temperature Specifications

    Standard operating temperature specifications NOTE: Not available: Indicates that the configuration is not offered by Dell EMC. Not supported: Indicates that the configuration is not thermally supported. NOTE: All components including the DIMMs, communication cards, M.2 SATA, and PERC cards can be supported with sufficient thermal margin if the ambient temperature is equal to or below to the maximum continuous operating temperature listed in these tables with the exception of the Mellanox DP LP card.
  • Page 11 Process 12x 3.5” 8x 3.5” 4x 3.5” 24x 2.5” 20x 2.5” 16x 2.5” 12x 2.5” 8x 2.5” 4x 2.5” No back DIMM HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs plane model count enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur...
  • Page 12 Process 12x 3.5” 8x 3.5” 4x 3.5” 24x 2.5” 20x 2.5” 16x 2.5” 12x 2.5” 8x 2.5” 4x 2.5” No back DIMM HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs plane model count enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur...
  • Page 13 Process 12x 3.5” 8x 3.5” 4x 3.5” 24x 2.5” 20x 2.5” 16x 2.5” 12x 2.5” 8x 2.5” 4x 2.5” No back DIMM HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs plane model count enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur...
  • Page 14 Table 16. Maximum continuous operating temperature for fabric dual processor configuration Process 12x 3.5” 8x 3.5” 4x 3.5” 24x 2.5” 20x 2.5” 16x 2.5” 12x 2.5” 8x 2.5” 4x 2.5” No back DIMM HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs plane...
  • Page 15 Process 12x 3.5” 8x 3.5” 4x 3.5” 24x 2.5” 20x 2.5” 16x 2.5” 12x 2.5” 8x 2.5” 4x 2.5” No back DIMM HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs plane model count enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur...
  • Page 16 Process 12x 3.5” 8x 3.5” 4x 3.5” 24x 2.5” 20x 2.5” 16x 2.5” 12x 2.5” 8x 2.5” 4x 2.5” No back DIMM HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs plane model count enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur...
  • Page 17 Process 12x 3.5” 8x 3.5” 4x 3.5” 24x 2.5” 20x 2.5” 16x 2.5” 12x 2.5” 8x 2.5” 4x 2.5” No back DIMM HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs HDDs plane model count enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur enclosur...

  • Page 18: Expanded Operating Temperature Specifications

    Table 19. Configuration Restrictions with Mellanox ConnectX-4 EDR Dual Port Card with Active (Optical) connectivity 3.5” chassis 2.5’ Chassis Backplane CPU TDP 12x HDDs 8x HDDs 4x HDDs 24x HDDs 16x HDDs 8x HDDs 4x Hdds 205W Not supported 200W 173W Not supported 165W...

  • Page 19: Fresh Air Operation

    Expanded operating temperature Specifications NOTE: Outside the standard operating temperature (10°C to 35°C), the system can operate down to –5°C or up to 45°C for a maximum of 1% of its annual operating hours. For temperatures between 40°C and 45°C, de-rate maximum allowable temperature by 1°C per 125 m above 950 m (1°F per 228 ft).

  • Page 20: Documentation Resources

    Dell OpenManage Essentials, see the Dell OpenManage Essentials User’s Guide. For information about installing and using Dell Dell.com/serviceabilitytools SupportAssist, see the Dell EMC SupportAssist Enterprise User’s Guide. For understanding the features of Dell Lifecycle Dell.com/idracmanuals Controller, see the Dell Lifecycle Controller User’s Guide.
  • Page 21 Task Document Location For information about partner programs enterprise Dell.com/openmanagemanuals systems management, see the OpenManage Connections Enterprise Systems Management documents. Working with the Dell For information about understanding the features Dell.com/storagecontrollermanuals PowerEdge RAID controllers of the Dell PowerEdge RAID controllers (PERC), Software RAID controllers, or BOSS card and deploying the cards, see the Storage controller documentation.

  • Page 22: Getting Help

    Getting help Topics: • Receiving automated support with SupportAssist • Contacting Dell • Documentation feedback • Accessing system information by using QRL Receiving automated support with SupportAssist Dell SupportAssist is an optional Dell Services offering that automates technical support for your Dell server, storage, and networking devices.

  • Page 23: Documentation Feedback

    Documentation feedback You can rate the documentation or write your feedback on any of our Dell documentation pages and click Send Feedback to send your feedback. Accessing system information by using QRL You can use the Quick Resource Locator (QRL) to get immediate access to the information about your system. The QRL is located on the top of the system cover and provides access to generic information about your system.
