Delete

2nd Tier
(Default = none) The following procedure describes how to
remove hardwire and wireless sensors from panel memory.
Note
Deleting zones/sensors does not delete text associated
with the deleted zone/sensor number.
To delete a device:
1. To select a different zone press
# to delete the displayed zone. The display
zones. Press
shows the next sensor.
2. Repeat step 1 until all desired zones are deleted.

Review

2nd Tier
(Default = none) This allows you to view the zone number and
the group for each learned zone or sensor. For example, the
display shows:
ZONE
01 10
GRP
where:
01 = zone/sensor number,
ZONE
10 = sensor group 10.
GRP
Review devices allows the installer to change the group
assigned to devices. The panel accepts the group numbers
defined in Table B1 in Appendix B.
To review a device:
1. To select a different zone press
zones. The display shows the current setting.
2. Enter the desired group number to modify then press #. The
display shows the new setting.

Text

2nd Tier
(Default = none) The panel allows sensor text to be associated
with each device. The sensor text consists of a prefix field,
base field, and suffix field. Table 4 shows the words available
for each field. The default text for zones 1-3 are:
Zone 1 - Phone Module (DTIM)
Zone 2 - Front Door
Zone 3 - Back Door
To add text:
1. To select the zone you want to add text to press
get to the correct zone then press
displayed.
2. Press # then to scroll thru the base words, press
select the word you want.
3. Press to change to the prefix words. Press
scroll thru the prefix words. Press
want.
4. Press to change to the suffix words. Press
scroll thru the suffix words. Press
want.
5. Press * to review what has been selected, then press
go to the next zone to change.
6. Repeat steps 2 thru 4 to change all zones.
Allegro
Preliminary 2/5/02
(Devices)
to scroll thru the learned
(Devices)
to scroll thru the learned
(Devices)
, till you
# . Base is the first to be
# to
# then to
# to select the word you
# then
to
# to select the word you
to
Table 4: Sensor Text
Prefix Field Base Field
None None
North Keychain
NE Touchpad
East Front
SE Back
South Garage
SW Bedroom
West Guest Room
NW Childs Room
Utility Room
Living Room
Dining Room
Bathroom
Laundry Room
Kitchen
Office
Den
Special Chime
Basement
Upstairs
Downstairs
Hallway
Medicine Cabinet
Closet
Attic
System Panic
Phone Module
Note
Some combinations of the sensor text selections are too
long for the display.
Suffix Field
None
Door
Window
Remote
Smoke
Emergency
Motion
Fire
Freeze
CO
0
1
2
3
4
5
6
7
8
9
9
