Table 6: Signal measurement characteristics (cont.)
Characteristic
RF Channel Carrier
Frequency
Units and Resolution
Accuracy
Accuracy using
YBGPS1 GPS Timing
Reference
RF Scout Quick Start User Manual
Description
Measures the frequency of the carrier in the user selected channel. The user can enter a channel
number or frequency.
MegaHertz (MHz): 1 Hz
± (10 Hz + Time Base Error), 99% confidence interval
W-CDMA: ± (12 Hz + Time Base Error), 99% confidence interval
Note: The carrier frequency must be within 10 kHz of the expected value, except:
W-CDMA, 1xEV-DO, and GSM/EDGE: within 5 kHz
IS-136: within 1.5 kHz
W-CDMA 3GPP Test Model 4
± (10 Hz + 0.015 ppm), typical
Note: The carrier frequency must be within 10 kHz of the expected value, except:
W-CDMA, 1xEV-DO, and GSM/EDGE: within 5 kHz
IS-136: within 1.5 kHz
The GPS antenna and the instrument antenna should be stationary for specified accuracy. Doppler
shift of BST frequency is ± 0.09 ppm when the instrument antenna is moving at 60 mph (100 km/hr).
Specifications
