INSTALLATION AND USER INSTRUCTIONS
Dear Customer,
thank you for having purchased one of our products.
We are certain that this new, modern, functional and practical appliance, built with the very highest
quality materials, will meet your requirements in the best possible way. This appliance is easy to
use. It is, however, important to thoroughly read the instructions in this handbook in order to obtain
the best results.
These instructions are only valid for the countries of destination, the identification symbols
of which are indicated on the cover of the instruction manual and on the appliance itself.
The manufacturer shall not be held responsible for any damages to persons or property
caused by incorrect installation or use of the appliance.
The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or
transcription errors; the designs in the figures are purely indicative. The Manufacturer also reserves the right
to make any modifications to the products as may be considered necessary or useful, also in the interests of
the user, without jeopardizing the main functional and safety features of the products themselves. This cook
top was designed to be used exclusively as a cooking appliance: any other use (such as heating
rooms) is to be considered improper and dangerous.
BUILT-IN GAS HOB DOMINO
GD-Z01 GD-Z02
COD. 04064LI - 2109.2016 rev 00
Advertisement
Table of Contents
Related Manuals for DUDOFF GD-Z01
Summary of Contents for DUDOFF GD-Z01
- Page 1 INSTALLATION AND USER INSTRUCTIONS BUILT-IN GAS HOB DOMINO GD-Z01 GD-Z02 Dear Customer, thank you for having purchased one of our products. We are certain that this new, modern, functional and practical appliance, built with the very highest quality materials, will meet your requirements in the best possible way. This appliance is easy to use.
-
Page 2: Description Of The Cooktop
DESCRIPTION OF THE COOKTOP 1 Ultra rapid burner of 4000 W 2 Rapid gas burner of 2800 W 3 Auxiliary gas burner of 1000 W 4 Pan stand support 1F Wok 5 Pan stand support 2F 6 Burner n° 1 control knob 7 Burner n°... - Page 3 1) TRADITIONAL BURNERS inner flame and the minimum of the outer flame. To turn off the burner, turn the knob clockwise, On the surface of the hob, there is a serigraphic realigning the indicator with the ● off symbol. figure above each knob, indicating the burner to which the knob refers.
- Page 4 their contents, causing accidents. - The pans must not extend beyond the edge of the Power Ø Pan Burners hob. (cm) - Containers wider than the unit are not 22 ÷ 27 recommended. complete DUAL 4750-5000 central DUAL 8 ÷ 16 Fast 2800 20 ÷...
- Page 5 WARNINGS AND ADVICE FOR THE USER: ●Use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventiladed by keeping the natural air vents clear (see fig. 3) and by activating the mechanical aeration device (suction hood or electric fan fig.
- Page 6 CLEANING IMPORTANT: - Ensure that the enamelled covers “A”, “B” and always disconnect the appliance from the gas “C” (fig. 6 and 7) are correctly positioned on the and electricity mains before carrying out any burner head. The covers are correctly cleaning operation positioned on the head when they are perfectly stable.
-
Page 7: Installation
INSTALLATION TECHNICAL INFORMATION FOR 3) INSTALLING THE COOKTOP THE INSTALLER Check that the appliance is in a good condition after having removed the outer packaging and internal wrappings from around the various loose parts. In IMPORTANT! case of doubt, do not use the appliance and contact A perfect installation, adjustment or qualified personnel. -
Page 8: Fixing The Cooktop
INSTALLATION 4) FIXING THE COOKTOP can be touched, we recommend fitting a protecting shield. This shield must least The cooktop has a special seal which prevents 70 mm below the base of the bench top (fig. 8). liquid from getting into the cabinet. Strictly comply Timber or other suitable material may be used with the following instructions in order to correctly provided it is capable of withstanding the appliance... -
Page 9: Room Ventilation
INSTALLATION IMPORTANT INSTALLATION standards and provisions in force. When gas is supplied through ducts,the SPECIFICATIONS appliance must be connected to the gas supply The installer should note that the appliance that system: side walls should be no higher than the cooktop ●... -
Page 10: Electrical Connection
INSTALLATION 8) ELECTRICAL CONNECTION a high sensitivity differential circuit- breaker. You are strongly advised to fix the relative yellow- The electrical connections of the appliance must green earth wire to an efficient earthing system. be carried out in compliance with the provisions and standards in force. -
Page 11: Replacing The Battery
INSTALLATION 8/A) INSTALLING THE HOT PLATE - Unscrew the ignition cap “T” (see fig. B) and fit a 1.5 V battery (not included in the appliance) with WITH THE BATTERY the positive “+” polarity turn inside. Check that the appliance is in a good condition after Rescrew the cap. - Page 12 ADJUSTMENTS Always disconnect the appliance from the It is understood that only burners operating with electricity main before making any adjustments. Natural should be subjected to the above All seals must be replaced by the technician at mentioned adjustments. The screw must be fully the end of any adjustments or regulations.
-
Page 13: Replacing The Injectors
CONVERSIONS 10) REPLACING THE INJECTORS The technician must reset any seals on the regulating or pre-regulating devices. The burners can be adapted to different types of gas by The envelope with the injectors and the labels can mounting injectors suited to the type of gas in question. be included in the kit, or at disposal to the To do this, first remove the burner tops using a wrench authorized Customer Care Department. - Page 14 SERVICING Always disconnect the appliance from the Greasing the taps (see fig. 19) electricity and gas mains before proceeding with If a tap becomes stiff to operate, it must be any servicing operation. immediately greased in compliance with the following instructions: - remove the tap.
- Page 15 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE COOKTOP CABLE POWER SUPPLY Gas cooktop H05 RR - F Section 3 X 0.75 mm ATTENTION!!! If the power supply cable is replaced, the installe should leave the ground wire longer than the phase (B) conductors (fig.
-
Page 16: Gas Models
TECHNICAL DATA ON THE DATA LABEL GAS MODELS 1 BURNERS 2 BURNERS 1 BURNERS UR 4 kW 5 kW DUAL Category = III Category =III Category = III G 30 - Butane = 30 mbar G 30 - Butane = 30 mbar G 30 - Butane = 30 mbar G 31 - Propane = 30 mbar G 31 - Propane = 30 mbar...
