- Page 1 ENMET 680 Fairfield Court Ann Arbor, MI 48108 734.761.1270 Fax 734.761.3220 www.enmet.com Recon B Series Operation and Maintenance Manual...
-
Page 2: Table Of Contents
Recon B Series ENMET Table of Contents ....................................2 1.0 I NTRODUCTION 1.1 Unpack ........................................2 1.2 Check Order ....................................... 2 1.3 Serial Numbers ......................................2 .....................................3 2.0 F EATURES 2.1 Recon/B Series Features..................................... 3 3.0 D ..............................4 ESCRIPTION OF USHBUTTONS ....................................5... -
Page 3: Introduction
If you need your shipments insured, please forward a written request to ENMET Customer Service. Regarding Shortages If there are any shortages or questions regarding this shipment, please notify ENMET Customer Service within 5 days of receipt at the following address: Items included with the Recon/B Series: ENMET ... -
Page 4: Features
Recon B Series ENMET 2.0 Features 2.1 Recon/B Series Features See Figure 1 for location of features: Feature Description Visual Alarms Red indicators clearly visible on 3 sides and located at the top of the Recon/B Series LED’s activate when alarm thresholds are exceeded... -
Page 5: Description Of Pushbuttons
Recon B Series ENMET LCD, Display Number Function Battery Lock sound vibration Alarming conditions Warning or the maximum level numeric value Error Not Used Clock Zero calibration Calibration point or calibration status Not Used Set-up of the parameters Indication of the gas concentration units Figure 2: Recon B Series Display 3.0 Description of Pushbuttons... -
Page 6: Operation
Recon B Series ENMET 4.0 Operation 4.1 Activation of the Recon B Series To activate the detector, press the P button and hold for 3 seconds. OWER The detector begins a self-test sequence, example listed below Display Test The LCD displays all of the screen elements. -
Page 7: Checking Recon/B Series Status
Recon B Series ENMET 4.3 Checking R /B S Status ECON ERIES To activate the detector, press the P button and hold for 3 seconds. OWER When the Recon/B Series has finished its startup sequence. Press UP and S buttons at the same time, the display will indicate Temp., time, STEL &... -
Page 8: Alarms
Recon B Series ENMET 4.5 Alarms When alarming continuously, you can press S button to turn off the audible alarm and vibration when the are flashing. The following table describes Recon/B Series alarms and shows examples of display for each alarm. -
Page 9: Automatic Zero Calibration
Recon B Series ENMET Time error In this condition, the device will try to renovate it by itself. If succeeded, after start-up, it enters the menu of time set up. Please set up the time according to the local time. If failed, the device will turn off. -
Page 10: Maintenance Of The Recon/B Series
Recon B Series ENMET 5.0 Maintenance of the Recon/B Series To maintain proper battery function and life the Recon should be operated once a week for 6 to 8 hours and then placed on charge see Section 5.3 The Recon/B Series maintenacne section allows access to Zero, Calibration, Calibration target gas and alarm point adjustment menus. -
Page 11: Calibration Point Adjustment
Recon B Series ENMET 5.1.3 Calibration Point Adjustment In this mode, display is the last concentration of gas used to calibrate the instrument. Press UP or Down button to modify the display. : Not used with Recon Oxygen units : 20.9% Oxygen is the only calibration level to be used with Recon Oxygen units... -
Page 12: Alarm Levels Adjustment Of The Recon/B Series
Recon B Series ENMET 5.2 Alarm Levels Adjustment of the Recon/B Series 5.2.1 Set up of L-alarm (Low Alarm) With the Recon/B Series Off press and hold the P and S buttons until unit activates. OWER When 0000 is displayed, enter the password, factory set to 1270, by using the UP button to increment the digit and the S button to accept the indicated digit and move the cursor. -
Page 13: Sensor Replacement
Sensor life in the Recon/B Series is typically: 2 years for Carbon Monoxide & Hydrogen Sulfide and 1year for Oxygen and Combustible. The sensor needs to be replaced when the Recon/B Series can no longer be calibrated or if the sensor becomes erratic. Contact ENMET for sensor replacement information. Table 1: Recon/B Series Factory Set Parameters Range... -
Page 14: Accessories And Replacement Parts
Recon B Series ENMET 7.0 Accessories and Replacement Parts 7.1 Replacement Sensor part numbers Sensor, % LEL Combustible Gasses 02542-005 Sensor, CO 02542-1200 Sensor, H2S 02542-0200 Sensor, Oxygen 02542-1100 Sensor, H2 02542-1500 Sensor, NH3 02542-2400 Sensor, SO2 02542-0500 7.2 Parts and Accessories... -
Page 15: Terms And Conditions
ENMET, LLC for damages arising out of or in connection with the use or repair or performance of the product. -
Page 16: Instructions For Returning An Instrument For Service
ENMET charges a one hour minimum billing for all approved repairs with additional time billed to the closest tenth of an hour. All instruments sent to ENMET are subject to a minimum evaluation fee, even if returned unrepaired. - Page 17 Mailing/Shipping Address: ENMET 680 Fairfield Court Ann Arbor, MI 48108 Phone: 734.761.1270 repair@enmet.com Fax: 734.761.3220 Service Request Form Product Name or Number: Product Serial Number: Describe Problem or Needed Service: Warranty Claim? ☐ Yes ☐ No CUSTOMER INFORMATION Billing Address:...
