DAMAGE IN TRANSIT Please contact your supplier without delay. Protect the
cover and visible parts of your fire from dirt and damage during installation
and transport
We recommend that you keep a suitable fire extinguisher for liquid fires
handy (fire class B).

2.4 INSTALLATION LOCATION

When choosing the installation location for your ebios-fire please ensure
the unit is not directly exposed to major heat sources such as radiators,
stoves, etc. and that it is not installed in a room where high temperatures
occur (e.g. a sauna).
Your ebios-fire must not be installed:
1. In stairwells and landings, except in residential buildings with no more
than two flats
2. In corridors accessible to the public
3. In garages
4. In rooms where highly flammable or explosive substances or mixtures
are processed, stored or manufactured in such quantities that ignition or
explosion would be hazardous.
5. In poorly ventilated spaces
6. In unsupervised areas accessible to the public
7. In areas not sufficiently protected from cross-draughts
8. On top (uninstalled) of tables, furniture, up against a wall, etc.
9. Outdoors without a protection against weather and high humidity
10. In the entrance areas of hotel lobbies where draughts are likely to be
more prevalent, and where substantial differences in air pressure can
be expected.
When setting up the ethanol canister it is important to ensure that it cannot
tip over. The canister should only be stored in bays or cupboards where
flammable gases cannot build up. There must be no sources of ignition in
the immediate vicinity of the ethanol canister and supply lines. Please note
that the ethanol canisters must be placed at a lower level than the burner
(not more than 4 m difference in height), as otherwise there may be an
uncontrolled escape of ethanol if a leak occurs. Therefore keep the lines as
short as possible (line length not more than 10 m) and protect the lines from
contact with sharp, pointed or rough objects.
If using the ebios-fire 5-litre canister, the canister storage space must be
not less than 350 mm x 180 mm x 240 mm (H x W x D) per canister. In addi-
tion, the design of the location must ensure that it does not allow flammable
gases to build up, it will contain any escaping ethanol and it will prevent
fire from spreading.

2.5 ASSEMBLY / INSTALLATION

The ebios-fire Quadra Inside Automatic I SL and II SL is a ready-to-use unit
for fitting into the top plate of a custom-made piece of furniture (flammable
materials) or a custom-built open fireplace (non-flammable materials).
Custom-built open fireplaces using the Quadra Inside Automatic I SL or II
SL do not require a flue.
Whether free-standing or wall-mounted, the ebios-fire unit must be aligned
horizontally and secured so that it cannot tip. The wall-mounted model
should be attached to the wall and the free-standing model should be fas-
tened to the wall or floor. Note the safety clearances (Fig. 10 radiant area).
Rear vents must not be closed or obstructed. Place the burner in the frame
provided in the Quadra Inside Automatic I SL oder II SL. The floor on which
free-standing units are placed must have sufficient load-bearing capacity. If
not, appropriate measures should be taken, e.g. using a board to spread the
load, in order to achieve the requisite safe loading capacity.
