2.6.2 FIRE PRECAUTIONS/MINIMUM DISTANCES
FROM WALLS
When positioning the custom-made furniture unit next to a non-flammable
wall, a minimum distance of 150 mm from the wall must be maintained at
the rear and at the side. The point of reference is the outer edge of the
Quadra Inside Automatic I SL or II SL housing (see Fig. 4 and 5).
Fig. 4 Minimum distances from a non-flammable wall
Fig. 5 Minimum distances in the corner of a room
There must be no objects above the burner.
Fig. 6 Minimum distance from ceiling
• A minimum distance of 1,000 mm from combustible building compo-
nents, furniture, decorations or curtains must be maintained at the sides
(see Fig. 7) to ensure sufficient protection from heat.There must be no
objects between the top of the ebios-fire unit and the ceiling of the room
(min. 1,000 mm) (see Fig. 6)!
Fig. 7 Minimum distances from flammable building components
