  • Page 1 Operating Instructions VEGAMIP R61 Receiving unit - Relay Document ID: 35786...

  • Page 2: Table Of Contents

    Maintenance ........................30 Rectify faults ........................30 Exchanging the electronics .................... 31 How to proceed if a repair is needed ................31 Dismount Dismounting steps......................32 Disposal ......................... 32 Supplement Technical data ........................ 33 Dimensions ........................36 VEGAMIP R61 • Receiving unit...

  • Page 3: Vegamip R61 • Receiving Unit

    Contents Safety instructions for Ex areas Please note the Ex-specific safety information for installation and op- eration in Ex areas. These safety instructions are part of the operating instructions manual and come with the Ex-approved instruments. Editing status: 2012-02-14 VEGAMIP R61 • Receiving unit...

  • Page 4: About This Document

    Action This arrow indicates a single action. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. VEGAMIP R61 • Receiving unit...

  • Page 5: For Your Safety

    K band range. The low transmitting power lies far below the internationally permitted limit value. When the instrument is used correctly, it presents no danger to human health. It may be operated without restriction outside of closed vessels. VEGAMIP R61 • Receiving unit...

  • Page 6: Ce Conformity

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAMIP R61 • Receiving unit...

  • Page 7: Product Description

    Alternatively, you can access the data via your smartphone: • Download the smartphone app "VEGA Tools" from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or •...
  • Page 8 The VEGAMIP 61 consists of the following components. Fig. 1: VEGAMIP 61 with plastic housing Emitting unit VEGAMIP T61 Receiving unit VEGAMIP R61 with control electronics Housing lid Housing with control electronics Process fitting Several antenna versions are available for different applications.

  • Page 9: Packaging, Transport And Storage

    Up to the time of installation, the packages must be left closed and stored according to the orientation and storage markings on the outside. Unless otherwise indicated, the packages must be stored only under the following conditions: VEGAMIP R61 • Receiving unit...

  • Page 10: Accessories And Replacement Parts

    JIS B 2210-1984, GOST 12821-80. You can find additional information in the supplementary instructions manual "Flanges according to DIN-EN-ASME-JIS" (Document-ID 31088). Electronics module The electronics module VEGAMIP R61 is a replacement part for microwave barriers of VEGAMIP series 60. You will find additional information in the following operating instruc- tions manual: • "Electronics module VEGAMIP R61 (receiving unit)" (Document-ID...

  • Page 11: Mounting

    Installations in areas where high humidity is expected (e.g. through cleaning processes) • Installations on cooled or heated vessels Mounting instructions Switching point If possible, install VEGAMIP 61 in a position where strong signal damping by the medium is expected. Avoid mounting the instrument too close to the vessel wall. Reflec- tions from the vessel wall or from vessel installation can influence the switching accuracy. VEGAMIP R61 • Receiving unit...
  • Page 12 For this reason, mount VEGAMIP 61 at a position in the vessel where no disturbances, e.g. from filling openings, agitators, etc., can occur. Non-metallic vessels Microwaves can penetrate non-conductive materials. Hence, it is pos- sible to measure through the wall of non-conductive vessels. VEGAMIP R61 • Receiving unit...
  • Page 13 Inspection glass < 200 mm Aluminiumoxide ceram- < 200 mm ic Al Abrasion protection (ce- < 100 mm ramic) Isolating material Mineral wool < 1000 mm Ceramic fibre plates < 1000 mm Fireclay bricks < 500 mm VEGAMIP R61 • Receiving unit...
  • Page 14 Fig. 7: Installation in pipelines Min. distance 100 mm (3.94 in) Mount the threaded version of VEGAMIP 61 in the following way: Threaded version VEGAMIP R61 • Receiving unit...
  • Page 15 In the case of VEGAMIP 61 with NPT thread, the instrument seals in the thread itself. Hence, no counter nut is necessary for these ver- sions. Buildup Avoid long sockets in which the medium can remain and if possible, mount VEGAMIP 61 front-flush. This applies mainly if buildup and dust are expected. VEGAMIP R61 • Receiving unit...
  • Page 16 Select the material according to the diameter of the socket and adapt the length as far as possible to the shape of the vessel wall. Secure the filling material against falling out or turning. If using a fixing screw is technically not possible, you can secure the material in the socket with an adhesive. VEGAMIP R61 • Receiving unit...
  • Page 17 In this case, you have to use a window material which is appropriately resistant. Vibrations In case of strong vessel vibrations, the VEGAMIP 61 should be mounted with anti vibration blocks or rubber buffers. VEGAMIP R61 • Receiving unit...
  • Page 18 Fig. 12: Orientation of the sensors - Angle and axis offset Polarisation direction The emitting unit emits electromagnetic waves. The polarisation plane is the direction of the electrical wave component. Its position is marked on the instrument hexagon by polarisation markings. VEGAMIP R61 • Receiving unit...
  • Page 19 With instrument versions with de- tachable horn antenna, the antenna extension can be retrofitted. To minimize false echoes, take note of the polarisation level. Keep the position of the polarisation marking to the antenna extension in mind. Mount the antenna extension according to the following illustration. VEGAMIP R61 • Receiving unit...
  • Page 20 4 Mounting Fig. 14: Possibilities for signal deflection Metal plate for signal deflection of the microwave signal Bent antenna extension Polarisation marking VEGAMIP R61 • Receiving unit...

  • Page 21: Connecting To Power Supply

    3. Remove approx. 10 cm (4 in) of the cable mantle, strip approx. 1 cm (0.4 in) of insulation from the ends of the individual wires 4. Insert the cable into the sensor through the cable entry VEGAMIP R61 • Receiving unit...

  • Page 22: Wiring Plan, Single Chamber Housing

    We recommend connecting VEGAMIP 61 in such a way that the switching circuit is open when there is a level signal, line break or failure (safe state). Information: The relays are always shown in non-operative condition. VEGAMIP R61 • Receiving unit...
  • Page 23 PLC inner resistance R > 100 kΩ, the additional load resistance R must be between 6.8 and 8.2 kΩ. Fig. 17: Wiring plan receiving unit - VEGAMIP 61 (receiver) when connecting to a PLC PLC/process control system Internal resistance of the PLC Additional load resistance (6.8 … 8.2 kΩ) Voltage supply VEGAMIP R61 • Receiving unit...

  • Page 24: Setup

    Mode switch (1) With the mode switch (max./min.) you can change the switching status of the relay. You can set the required mode according to the "Function chart" (max. - maximum detection or overflow protection, min. - minimum detection or dry run protection). VEGAMIP R61 • Receiving unit...

  • Page 25: Adjustment

    Switching status Signal lamp - Re- lay (yellow) Mode max. Overflow protection (6) (7) Relay energized Mode max. Overflow protection (6) (7) Relay deenergized Mode min. Dry run protection (6) (7) Relay energized Mode min. Dry run protection (6) (7) Relay deenergized VEGAMIP R61 • Receiving unit...
  • Page 26 "-->" key makes the sensor less sensitive. Press the respective key until the indication is within the LED indica- tion strip. This means one or two LEDs on the LED indication strip will light up. VEGAMIP R61 • Receiving unit...
  • Page 27 The indication of the LED indicating strip does not change, but the instrument will become a little less sensitive with each pressing of the key. VEGAMIP R61 • Receiving unit...
  • Page 28 Fig. 37: LED indicating strip - Setting for products with weak signal damping Switching delay You can adjust the switching delay with the help of the LED indicating strip. Push the two keys (7) and (8) simultaneously for approximately 2 s until the LED indication flashes. VEGAMIP R61 • Receiving unit...
  • Page 29 10 s. Simulation If possible, simulate a filling between emitting and receiving unit with your hand or a metal sheet and check if the switching point is adjusted correctly. If the control lamp changes its switching status, the switching function is correct. VEGAMIP R61 • Receiving unit...

  • Page 30: Maintenance And Fault Rectification

    Depending on the reason for the fault and the measures taken, the Reaction after fault recti- fication steps described in chapter "Setup" must be carried out again or must be checked for plausibility and completeness. VEGAMIP R61 • Receiving unit...

  • Page 31: Exchanging The Electronics

    24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside normal working hours, seven days a week around the clock.

  • Page 32: Dismount

    Pass the instrument directly on to a spe- cialised recycling company and do not use the municipal collecting points. These may be used only for privately used products according to the WEEE directive. VEGAMIP R61 • Receiving unit...

  • Page 33: Supplement

    Process fittings Ʋ Pipe thread, cylindrical (ISO 228 T1) G1½ Ʋ American pipe thread, conically 1½ NPT Ʋ Flanges DIN from DN 50, ASME from 2" Ʋ Mounting adapter G2 or 2 NPT Frequency range K band, 24.085 GHz (ISM band) VEGAMIP R61 • Receiving unit...
  • Page 34 Min. distance 100 mm (3.94 in) Ambient conditions Ambient, storage and transport tempera- -40 … +80 °C (-40 … +176 °F) ture Process conditions Measured variable Limit level of bulk solids and liquids Outside the specified beam angle, the energy of the radar signal has a level of -3 dB (50 %) VEGAMIP R61 • Receiving unit...
  • Page 35 U >60 V DC, the ambient temperature can be max. 50 °C/122 °F) Power consumption 2.5 VA (AC), approx. 1.3 W (DC) Electrical protective measures Protection rating IP 66/IP 67 (NEMA 4X) Overvoltage category Protection class Approvals Instruments with approvals can have different technical specifications depending on the version. Note max. pressure of the process fitting VEGAMIP R61 • Receiving unit...

  • Page 36: Dimensions

    9 Supplement For that reason the associated approval documents of these instruments have to be carefully noted. They are part of the delivery or can be downloaded under www.vega.com, "VEGA Tools" and "Instrument search" as well as under www.vega.com/downloads and "Approvals".
  • Page 37 1½" ø40 2" ø48 3" ø75 4" ø95 SW 46 mm inch (1.81") 3.94" ø1.58" 1½" 4.72" ø1.89" 2" G1½A / 1½ NPT 8.50" ø2.95" 3" 16.93" ø3.74" 4" Fig. 42: VEGAMIP 61, horn antenna/316L VEGAMIP R61 • Receiving unit...
  • Page 38 (2.4") Fig. 43: Mounting adapter with ceramic cover for VEGAMIP 61 with internal horn antenna, threaded version G1½ with PTFE cover (also with 1½ NPT thread) 150 mm (5.9 in) or 300 mm (11.8 in) VEGAMIP R61 • Receiving unit...
  • Page 39 Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com.
  • Page 40 Operation 24 Orientation of the sensor 18 Pipelines 14 Polarisation direction 18 Potential equalisation 21 Receiving unit 8, 23, 24 Repair 31 Sensitivity adjustment 26 Service hotline 31 Shielding 21 Simulation 29 Switching delay 28 VEGAMIP R61 • Receiving unit...
  • Page 41 Notes VEGAMIP R61 • Receiving unit...
  • Page 42 Notes VEGAMIP R61 • Receiving unit...
  • Page 43 Notes VEGAMIP R61 • Receiving unit...
  • Page 44 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2014 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
