AES In 1 thru 16 (DB25)

All inputs support AES 42
AES
INPUT
Input 1/2 ( + )
Input 1/2 ( – )
Input 3/4 ( + )
Input 3/4 ( – )
Input 5/6 ( + )
Input 5/6 ( – )
Input 7/8 ( + )
Input 7/8 ( – )
Input 9/10 ( + )
Input 9/10 ( – )
Input 11/12 ( + )
Input 11/12 ( – )
Input 13/14 ( + )
Input 13/14 ( – )
Input 15/16 ( + )
Input 15/16 ( – )
Ground pins 2, 5, 8, 11, 16, 19, 22, 25
DB25 PIN NUMBER
24
12
10
23
21
9
7
20
18
6
4
17
15
3
1
14
60
Wiring Configuration
