Mixer Faders

The MIXER FADERS key assigns input(s) and sets functions to the faders of a Mix 16 control panel.

Slecting a fader bank to assign

Tap on the arrow keys on either side of the BANK key to select one of the 5 Mix16
fader banks.

Slecting fader groups

Tap on the EXT FADER key on the top left to toggle between fader groups 1 thru 8
and fader groups 9 thru 16.

Assigining a trim pot function to a fader strip

Tap on the box above the fader to assign a function to that trim pot.
Z - The fader will control the input gain from a Zaxcom wireless transmitter for
•
the selected input.
T - The fader will control the input trim for the selected input.
•

Assigining an input(s) to the fader

Tap on the fader to open the fader assign matrix. From the matrix any analog or
digital input(s) can be assigned to a Mix16 fader. Multiple inputs can be assigned to
any fader.
