Deluxe Inversion Table
Model IT9630-A
Version: 201411
CAUTION:
WARNING: DO NOT USE THIS
INVERSION TABLE WITHOUT A
PHYSICIAN'S APPROVAL
It is recommended that Inverting
upside down be supervised.
Do not let children use the
inversion table unsupervised.
Read all instructions carefully
before using.
Tighten all bolts before using
equipment.
Leave adequate space to
properly invert.
Questions/ Comments
PLEASE DO NOT CONTACT THE
STORE FOR PARTS OR
SERVICE QUESTIONS
Extreme Products Group is committed to
providing the very best of quality and
customer satisfaction for all of the products
we distribute. If for any reason , you are
dissatisfied with the product you have
purchased or need assistance in any way,
please do not hesitate to contact our
knowledgeable support staff as follows:
Phone:623-888-6379
Email: service@extremeproductsgroup.com
Web: www.extremeproductsgroup.com
Photo may differ from actual product
Mon.-Fri 9:00 am – 5:00 pm Phoenix Time
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elite Fitness IT9630-A
Summary of Contents for Elite Fitness IT9630-A
- Page 1 Deluxe Inversion Table Model IT9630-A Version: 201411 CAUTION: WARNING: DO NOT USE THIS INVERSION TABLE WITHOUT A PHYSICIAN’S APPROVAL It is recommended that Inverting upside down be supervised. Do not let children use the inversion table unsupervised. Read all instructions carefully before using.
- Page 2 BEFORE BEGINNING ASSEMBLY… Take a few moments to familiarize yourself with the specific parts and hardware included with your product. Make sure all the parts and hardware are included in the carton and examine them for any damage that may have occurred in transport. Some parts may be pre-assembled and pre-installed. CAUTION WARNING: BEFORE STARTING ANY INVERSION PROGRAM, CONSULT YOUR PHYSICIAN.
-
Page 3: Parts Listing
Parts Listing PARTS LISTING-MODEL IT9630 INVERSION TABLE Part# Description check Part# Description check Head pad Hexagonal Bolt-M8*20 Backrest Support Tube Bolt-M8*20 Bodt Height Adjustment Tube Oval End Caps-Foot Rest Foot Rest Plate Base Frane End Caps Adjustable Leg Hold Tube Square End Cap-for Part3 Handlebar-RIGHT Stopper... -
Page 4: Exploded View
Exploded View * For Any Parts Required, DO NOT CALL TECHNICAL SUPPORT. Please visit our web site: www.extremeproductsgroup.com * For Any Parts Required, DO NOT CALL TECHNICAL SUPPORT. Please visit our web site: www.extremeproductsgroup.com... -
Page 5: Step 1- Unfold Frame
Step 1- Unfold Frame Carefully remove Base Frame (8&9) from carton, and unfold. Note Front, Rear, Right and Left Sides for further assembly Insert Safety Pin on Rt Side * For Any Parts Required, DO NOT CALL TECHNICAL SUPPORT. Please visit our web site: www.extremeproductsgroup.com... -
Page 6: Step 2- Handlebar Assembly
Step 2- Handlebar Assembly Reinforcement Bolt Note: Right Handlebar has Built in Bracket Right Left Rear Front STEP 2 Attach the Right Handlebar (6) to the Right Side Base Frame using 2 Bolts (20), 2 Washers (19), and 2 Nuts (21). Use Bolt (52) and Flat Washer (19) to reinforce the Incline Adjustment Bracket to the Base Frame. - Page 7 Step 3- Backrest Assembly to Base Frame Note: Rotational Side Brackets must face DOWN toward floor Right Left Lift Entire Bed Assembly UP into Rotational Brackets And Secure with Bolts, Nuts, and Washers Rear Front STEP 3 Connecting Backrest Pad & Assembly to Frame Attach the Completed Backrest Pad Assembly to the Rotational Brackets of the Base frame Unit using Bolts (29), Flat Washers (19) and Lock Nuts (21) as shown...
- Page 8 STEP 4 -Body Height Adjustment Tube and Rollers A- Install Foot Rest Plate (4) into Height Adjustment Tube (3) using Hexagonal Bolts (41), & Flat Washers (19) B- Lift out front roller tube (5) from Height Adjustment Selector Tube (3) and position as shown. Slide Foam Rollers (13) over front Tube (5) and insert Plastic End Caps (36) C- Insert Rear Foam Roller Tube (10) through...
-
Page 9: Step 5 -Final Assembly
STEP 5 -Final Assembly Note: Safety Pin Goes Here Slide Completed Height Adjustment Tube and Foot Rest Assembly (3) into Backrest Support Tube (2) and lock into place using Height Adjustment Knob (38) and Safety Pin (26) Note: This product is designed to adjust from 5’1” to 6’6” with a Maximum User Weight of 300 LBS. - Page 10 PRECAUTIONS WARNING: 300 LB WEIGHT CAPACITY To reduce the risk of serious injury, read all important precautions instructions and warnings in this manual before using the Inversion System. Extreme Products Group assumes no responsibility for personal injury or property damage sustained by or through the use of the Inversion System.
-
Page 11: Usage Guidelines
USAGE GUIDELINES INVERSION SELECTOR PIN Familiarize yourself with the Inversion Selector Pin located on the Right Side of the Inversion Table. The positioning of the pin will determine the degree of Inversion that you are comfortable with. The 3 selections are: 20- Slight Inversion 40-Moderate Inversion 60- Enhanced Inversion... - Page 12 USAGE GUIDELINES- Securing Feet and Ankles Step 2- Slide Feet under Foam Rollers and rest heels against rear Heel Cups. Release top button and slowly “ratchet back” front rollers against legs. Step 3- Ratchet front rollers tight against legs and secure legs and ankles in place by making sure leg assembly “LOCKS”...
- Page 13 USAGE GUIDELINES- How to Invert * For Any Parts Required, DO NOT CALL TECHNICAL SUPPORT. Please visit our web site: www.extremeproductsgroup.com...
- Page 14 Distributed By: Extreme Products Group 6635 W. Happy Valley Rd. Suite A-104, #213 Glendale, AZ 85310 Phone: 623-888-6379 Fax: 623-434-9100 service@extremeproductsgroup.com Note: For all parts requests, please visit our web site: www.extremeproductsgroup.com...
