Elite Fitness R9 DUAL MODE ROWER Assembly Instruction Manual

Table of Contents

Need help?

Do you have a question about the R9 DUAL MODE ROWER and is the answer not in the manual?

Page 2 R9 DUAL MODE ROWER ASSEMBLY INSTRUCTIONS Introduction Table of Contents Congratulations on your purchase of the R9 Dual Mode Rower. This product has been Introduction page 1 designed and manufactured to meet the needs and requirements of domestic use. Table of Contents page 1 Please carefully read the instructions prior to assembly and first use.
Page 3 6 x BOLT [319] and tighten firmly. Open the carton as shown in the diagram below. c) Connect AC ADAPTOR CABLE [712] to AC CABLE NOTE: To protect the R9 Dual Mode Rower while [720]. assembling we suggest that you do not remove the...
Page 4 It is important to read the Owner’s Manual and all NOTE: Ensure that the 2 x SEAT CARRIAGE COVER safety instructions thoroughly to familiarize yourself [117] engage correctly into each other as shown in the with the R9 Dual Mode Rower before using it. diagram below. CARRIAGE STEP 9 a) Connect the AC ADAPTOR [715] into the main power socket.
Page 5 R9 DUAL MODE ROWER PARTS LIST PART PART PART DESCRIPTION Q’TY DESCRIPTION Q’TY DESCRIPTION Q’TY ALUMINUM BEAM FOAM GRIP BOLT MAIN FRAME CARRIAGE STOPPER 362A BOLT PIVOT BRACKET COVER VENT BOLT 370B STABILIZER - FRONT STRAP SLOT TRIM BOLT STABILIZER - REAR POLY “V”...
Page 6 R9 DUAL MODE ROWER EXPLODED DRAWING Style No. R9 October 2012...
