GPS Connection

The data logger searches for a GPS signal when the
meter is powered up. If a signal is found, latitude
and longitude values will be added to the data file. If
a GPS signal is not found when powering up, the
meter will not search for it when taking readings. If
the meter is turned off and back on, it will again
search for the GPS signal. Be sure the meter is in
Measurement mode (see p. 4) before taking any
readings.
When taking a geo-referenced data measurement,
the LED will turn off while collecting the GPS signal.
The meter is again ready to take a reading when the
LED returns to a steady glow. If the data logger
loses the GPS signal, the LED will flash briefly be-
fore returning to Measurement mode. In this case,
check the GPS battery status as well as the connec-
tion to the pH data logger.
GPS Settings
Your GPS unit should be set to NMEA 0183 input/
output messages. This standard requires your unit
be set to the following:
GGA data string
4800 baud rate
Timing - 1 second
8 data bits
No parity
1 stop bit
Tip: If you have your GPS unit set properly and
have checked the connection but still are not get-
ting geo-referenced data, uncheck the box re-
quiring the digital correction in Meter Settings
(pp. 8 - 9) .
