GPS Connection

The data logger searches for a GPS signal when the
meter is powered up. When a signal is detected, the
meter's flash pattern will change from simply blinking
on and off to a pattern of 3 quick flashes separated
by a short pause. If a signal is found, latitude and
longitude values will be added to the data file (see p.
8). If a GPS signal is not found when powering up,
the meter will not search for it when taking readings.
If the meter is turned off and back on, it will again
search for the GPS signal. Be sure the meter is in
Measurement mode (see p. 7) before taking any
readings.
When taking a geo-referenced data measurement,
the LED will turn off while collecting the GPS signal.
The meter is again ready to take a reading when the
LED returns to a steady glow.
loses the GPS signal, the LED will flash briefly be-
fore returning to Measurement mode. In this case,
check the GPS battery status as well as the connec-
tion to the data logger.
GPS Settings
Your GPS unit should be set to NMEA 0183 input/
output messages. This standard requires your unit
be set to the following:
GGA data string
Timing - 1 second
No parity
Tip: If you have your GPS unit set properly and
have checked the connection but still are not get-
ting geo-referenced data, uncheck the box re-
quiring the digital correction in "Meter Settings"
screen (pp. 10 - 11) .
6
If the data logger
4800 baud rate
8 data bits
1 stop bit
