- Page 1 Please read this manual thoroughly and follow the installation procedures to prevent any damage to the CS-12 and or the connecting devices. ® ©Copyright 1999 ATEN International Co., Ltd. Manual Part No. PAPE-1143-100 Printed in Taiwan 02/1999 All brand names and trademarks are the registered property of their respective owners...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Overview Features Hardware Requirements Console Cables Unpacking Top View CPU Port View Console View Installation Operation Manual Port Selection Hot Key Port Selection Appendix Troubleshooting Specifications Radio & TV Interference Statement Limited Warranty... -
Page 3: Overview
The Master View CS-12 KVM Switch is a control unit that allows access to two PC systems from a single console (keyboard, mouse, and monitor). Before the development of the Master Vi e w, the only way to control multiple computer configurations from a single console was through a complex and costly network system. -
Page 4: Features
• Easy to Install - No Software Required - Standard Cables to Connect to the PCs Is All It Takes • Easy to Operate - PC Selection Via Pushbutton Switch or Hot Keys - Auto Scan Function to Monitor PC Operation •... -
Page 5: Hardware Requirements
Hardware Requirements Console • One VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using on any PC in the installation • One PS/2 mouse • One PS/2 style keyboard or AT style keyboard plus keyboard adapter The following equipment must be installed on each PC that is to be connected to the system:... -
Page 6: Unpacking
Check to make sure that the unit was not damaged in shipping. If you discover a problem, contact your dealer. Read the manual t h o r o u g h l y, and follow the installation and operation procedures carefully in order to prevent any damage to the unit and/or any devices it connects to. -
Page 7: Top View
Top View: 1. Port Selection Button Pressing the Selection Button switch access back and fort h between the PCs. The Selected LED lights to indicate which port is the active one. 2. Selected LEDs: Lights to indicate the currently selected port. Depending on the p o rt’s status, the LED may flash according to a specific pattern... -
Page 8: Cpu Port View
CPU Port View: 1. Video Connector 2. PS/2 Style Keyboard Connector 3. PS/2 Style Mouse Connector Console View: 1. PS/2 Style Mouse Connector 2. PS/2 Style Keyboard Connector 3. Monitor Connector... -
Page 9: Installation
Before you begin, make sure that power to all the devices (Master View CS-12 and both PCs) you will be connecting up have been turned off. 1. Plug the monitor, keyboard, and mouse into the Console port connectors of the Master View CS-12 unit. 2. -
Page 10: Operation
Manual Port Selection With Manual Po rt Selection you simply press the Po rt Selection button on the Master Vi e w ’s right side to switch back and fort h between computers. The Selected LED on the top panel lights to indicate which port is active. -
Page 11: Selecting The Active Port
[Spacebar] in order to use the console for anything else. Last/Next Mode: The Last/Next feature is provided to enable you to quickly switch back and forth between computers in order to monitor them manually, instead of using Auto Scan Mode. This method lets you dwell on a particular port for as long or as little as you like - as opposed to Auto Scan Mode, which switches after a fixed interval. - Page 12 To invoke Last/Next Mode, key in the following Hot Key combination: 1. Press and release Alt+Ctrl+Shift 2. Press and release 9 3. Press [Enter] Once Last/Next Mode is active pressing the left Shift key (LShift ) , switches to the previous computer (from the currently active one); pressing RShift switches to the next computer in the installation.
-
Page 13: Appendix
(with extra buttons and wheels) which can be used as either a PS/2 or serial mouse when they are in serial mode - switch the mouse to PS/2 mode if you wish to use the extra buttons/wheels. If the problem persists, change the mouse and/or mouse driver. -
Page 14: Specifications
Master View unit. If you connect the mouse port, you will need to use the notebook’s keyboard when you switch to make the notebook the active computer. -
Page 15: Radio & Tv Interference Statement
Radio & TV Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Pa rt 15 of the FCC Ru l e s . These limits are designed to provide reasonable protection against h a rmful interference in a residential installation.
