4) DMX MODE:
The laser can be controlled by any standard DMX-controller in 2 different DMX-modes:
• 2 CHANNEL MODE: for extremely easy setup and use! (display shows "2-h")
• 10 CHANNEL MODE: for full control of all possibilities. (display shows "10h")
• Connect the DMX input of the laser to the DMX output of the previous unit in the chain or directly to the
DMX-output of your controller.
• Press the [MENU] button to select the desired DMX-mode. (2-h or 10h)
• Press the [ENTER]-button to confirm your choice.
• Press the [UP / DOWN] buttons to choose the desired DMX-address (from 001 to 503 (10h) or 001 to
511 (2-h))
• Press the [ENTER]-button to confirm your choice.
Please refer to the DMX-chart below for the functions of the different channels.
Some more information on DMX512:
The DMX-protocol is a widely used high speed signal to control intelligent light equipment. You need to
"daisy chain" your DMX controller and all the connected light effects with a good quality XLR M/F
balanced cable. To prevent strange behavior of the light effects, due to
interferences, you must use a 90Ω to 120Ω terminator at the end of the chain. Never
use Y-splitter cables, this simply won't work!
Each effect in the chain needs to have its proper starting address so it knows which
commands from the controller it has to decode.
2 channel DMX MODE:
CHANNEL
CH 1
CH 2
JB SYSTEMS ®
VALUE
Blackout
000‐015
Program 1
016‐035
Program 2
036‐055
056‐075 Program 3
076‐095 Program 4
096‐115 Program 5
116‐135 Program 6
136‐155 Program 7
156‐175 Program 8
176‐195 Program 9
196‐215 Program 10
216‐235 Program 11
236‐255 Program 12
000‐200 Program speed
201‐255 Programs will run sound activated
