  • Page 1 MANUAL ENGLISH Astro 360 XL Ordercode: 43024 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...

  • Page 2: Table Of Contents

    Astro 360 XL Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Features ..................................7 Overview ..................................

  • Page 3: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes:  Showtec Astro 360 XL  IEC power cable (1 m) ...
  • Page 4 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.

  • Page 5: Operating Determinations

    Astro 360 XL • The user is responsible for correct positioning and operating of the Astro. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. • This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to earth.

  • Page 6: Connection With The Mains

    Astro 360 XL The Astro can be placed on a flat stage floor or mounted to any kind of truss with a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug.

  • Page 7: Return Procedure

    Astro 360 XL Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.

  • Page 8: Description Of The Device

    Astro 360 XL Description of the device Features The Showtec Astro 360 XL is a moving head fixture with high output and great effects.  Input voltage: 100-240V AC, 60/50 Hz  Power consumption: 175W  Light source: 8 x 12W 4-in-1 RGBW LEDs ...

  • Page 9: Frontside

    Astro 360 XL Frontside Fig. 02 01) 8 x 12W 4-in-1 RGBW LEDs 02) LCD display + control buttons Ordercode: 43024...

  • Page 10: Backside

    08) Fuse F3AL/250V 09) Ground/earth connection Installation Remove all packing materials from the Astro 360 XL. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly.

  • Page 11: Control Modes

    Astro 360 XL Control Modes There are 5 modes: • Auto • Manual • Sound-controlled • Master/Slave • DMX-512 (20CH, 52 CH) One Astro (Auto and Manual) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.

  • Page 12: Multiple Astros (Dmx Control)

    Astro 360 XL Multiple Astros (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the Astros and other devices.

  • Page 13: Fixture Linking

    Astro 360 XL Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.

  • Page 14: Control Panel

    Astro 360 XL The Astro 360 XL can be operated with a controller in control mode or without the controller in stand-alone mode. Control Panel A) LCD display MODE button C) UP button D) DOWN button ENTER button Fig. 06 Control Mode The fixtures are individually addressed on a data-link and connected to the controller.

  • Page 15: Menu Overview

    Astro 360 XL Menu Overview Ordercode: 43024...

  • Page 16: Main Menu Options

    Astro 360 XL Main Menu Options DMX Address DMX Mode / Master-Slave / Auto / Sound-controlled / Manual Pan and Tilt Reverse / Screen Reverse / Pan and Tilt Angle / Fans / Display / Sound Sensitivity / Dimmer Curves and Speed / Reset / Factory Settings...

  • Page 17: Operation Modes

    Astro 360 XL Operation Modes You can select 6 different operation modes when using the Astro. 01) In the main menu, press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to select one of the 6 modes: 1.

  • Page 18: Manual Mode

    Astro 360 XL 5. Manual Mode In this menu you can adjust various settings. 01) In the main menu, press the UP/DOWN buttons to choose MANUAL. 02) Press the ENTER button to open the menu. The display will show: 03) Press the UP/DOWN buttons to toggle through the options below.

  • Page 19: Advanced Settings

    Astro 360 XL Advanced Settings 01) In the main menu, press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. The display will show: 03) Press the UP/DOWN buttons to toggle through the options below: ...

  • Page 20: System Information

    Astro 360 XL System Information In this menu you can see the current active mode, the active DMX address, the current software version and the temperature of the device. 01) In the main menu, press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu and view the information.

  • Page 21: Dmx Channels

    Astro 360 XL DMX Channels 20 Channels Channel 1 – Horizontal movement (Pan) Move the slider up, in order to move head horizontally (PAN). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be turned by 540° and stopped at any position you wish.
  • Page 22 Astro 360 XL Channel 14 – Color Macros Dimmer and shutter must be open Not functional 1-239 Manual color adjustment 240-247 Color flow, fast to slow 248-255 Color switch, fast to slow Channel 15 – Built-in programs Dimmer and shutter must be open...
  • Page 23 Astro 360 XL Channel 19 – Functions Not functional 10-14 Pan/Tilt blackout 15-49 Pan/Tilt blackout OFF 50-54 No Function 55-59 No Function 60-64 No Function 65-69 Not functional 70-74 All reset 75-79 Not functional 80-84 Pan/Tilt reverse 85-89 Pan reverse...
  • Page 24 Astro 360 XL 52 Channels Channel 1 – Horizontal movement (Pan) Move the slider up, in order to move head horizontally (PAN). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be turned by 540° and stopped at any position you wish.
  • Page 25 Astro 360 XL Channel 16 – LED 1 Blue Dimmer and shutter must be open 0-255 Gradual adjustment Blue, from 0-100% Channel 17 – LED 1 White Dimmer and shutter must be open 0-255 Gradual adjustment White, from 0-100% ...
  • Page 26 Astro 360 XL Channel 48 – Built-in program speed No Function 1-127 Clockwise program, from slow to fast 128-255 Counterclockwise program, from slow to fast Channel 49 – Dimmer 0-255 0-100% dimmer Channel 50 – Shutter Dimmer and CH10-45 must be open...

  • Page 27: Maintenance

    04) The electric power supply cables must not show any damages or material fatigue. The Astro 360 XL requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth.

  • Page 28: Troubleshooting

    Response: Suspect three potential problem areas as: the power supply, the LEDs, the fuse. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the Astro to your Showtec dealer. 03) The fuse. Replace the fuse. See page 26 for replacing the fuse.
  • Page 29 Astro 360 XL Problem Probable cause(s) Solution • Check if power is switched on and One or more No power to the fixture fixtures do not cables are plugged in function at all Primary fuse blown • Replace fuse Fixtures reset The controller is not connected.

  • Page 30: Product Specifications

    Astro 360 XL Product Specifications Model: Showtec Astro 360 XL Input Voltage: 100-240V AC, 60/50Hz Power consumption: 175W DMX linking: 30pcs Fuse: F3AL/250V Dimensions: 354 x 354 x 435 mm (LxWxH) Weight: 17,32 kg Operating and Programming: Signal pin OUT:...

  • Page 31: Dimensions

    Astro 360 XL Dimensions Ordercode: 43024...
  • Page 32 ©2016 Showtec...
