Instructions
ProMix
Advanced Web
Interface
Installation and program setup instructions to allow communication between a PC and the
®
ProMix
PD2K Proportioner, via an Ethernet. For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
®
Kit 24T805, ProMix
PD2K Advanced Web Interface
(AWI)
Kit 15V337, Advanced Web Interface (AWI)
Important Safety Instructions
Read all warnings and instructions in this
manual and in your PD2K Proportioner
manual. Save all instructions.
®
PD2K
3A3170A
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProMix PD2K and is the answer not in the manual?

Questions and answers

Related Manuals for Graco ProMix PD2K

Summary of Contents for Graco ProMix PD2K

  • Page 1 Instructions ® ProMix PD2K Advanced Web 3A3170A Interface Installation and program setup instructions to allow communication between a PC and the ® ProMix PD2K Proportioner, via an Ethernet. For professional use only. Not approved for use in explosive atmospheres or hazardous locations. ®...

  • Page 2: Table Of Contents

    Configuration ......8 Graco Information ......24 Configuration for PD2K .

  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.

  • Page 4: Install The Advanced Web Interface (Awi) Module

    PC over an Ethernet, enabling users to monitor ment, fluid, hoses, and stress caused during opera- the ProMix PD2K, view and change system setup tion. parameters, and create reports.

  • Page 5: Connect The Awi Module To The Pd2K And Pc

    PD2K 1. Shut off the ProMix PD2K power (0 position) and shut off the power at the main circuit breaker. 5. Power up the AWI module. For instructions, see the 2.
  • Page 6 Install the Advanced Web Interface (AWI) Module AWI Module AWI Hub . 1: ProMix Network Typical Installation 3A3170A...
  • Page 7 Install the Advanced Web Interface (AWI) Module LAN Switch AWI Module . 2: Local Area Network (Manual) Typical Installation 3A3170A...

  • Page 8: Configuration

    1. Follow the system configuration steps in the Advanced Web Interface Kit manual 332459. 2. Connect the Graco Modbus TCP gateway in a series with the PD2K system. For instructions, see the ProMix PD2K Modbus TCP Installation Kit manual 3A3180.

  • Page 9: Configuration For Awi And Pd2K

    Configuration Setting Up AWI Follow these steps to set up AWI for each PD2K. 1. Verify that you are using AWI version 3.02.009 or later. 2. Add a new gateway. a. On the Network tab, under Gateway, click Add to add a new gateway. For more information, see Add or Remove Gateways in the Advanced Web Interface Kit manual 332459.
  • Page 10 Configuration d. In the Gateway Address field, type the IP address from System Screen 4 of the PD2K. See step 3 in the Setting Up PD2K section. e. Click Add. 3. Add the PD2K device. a. On the Network tab, under Devices, click Add. b.
  • Page 11 Configuration c. In the Device Address field, type 1. d. Click Add. The newly added PD2K system appears on the Network window. 4. Click the device icon to navigate to the PD2K AWI. 3A3170A...

  • Page 12: Operation

    Operation Operation Navigation Overview Top Navigation Tabs at the top of the screen provide quick access to various PD2K options. • Monitor – Click this tab to access the real time PD2K system monitor, which is similar to the ADM run screen. •...

  • Page 13: Monitor Screen

    Operation Monitor Screen The Monitor screen displays real-time system information such as pump modes, flow rates, materials, and pressure. For more information, see the Run Mode Screens section of the ProMix PD2K Electric Proportioner manual 332562. 3A3170A...

  • Page 14: Setup Screens

    The system configuration screen allows you to configure system setup information such as tolerances, hose settings, and flow control. The system configuration screen appears as the default screen when you click the Setup tab. For more information, see the sections for System Screens 1, 2, and 3 in the ProMix PD2K Electric Proportioner manual 332562.
  • Page 15 The recipe configuration screen allows you to configure information for a recipe, such as color, flush, catalyst, pres- sure, ratio, and potlife time. To access the recipe configuration screen, click the Setup tab and then click Recipe. For more information, see the Recipe Screens section of the ProMix PD2K Electric Proportioner manual 332562. 3A3170A...
  • Page 16 To access the recipe configuration screen, click the Setup tab and then click Flush. For more information, see the Flush Screen section of the ProMix PD2K Electric Proportioner manual 332562. 3A3170A...
  • Page 17 The advanced system configuration screen allows you to configure data for display, units, and USB. To access the recipe configuration screen, click the Setup tab and then click Advanced. For more information, see the sections for Advanced System Screens 1, 2, 3, and 4 in the ProMix PD2K Electric Pro- portioner manual 332562.
  • Page 18 Operation System Material-Valve Assignment Screen The material-valve assignment screen associates a PD2K valve to a material in master material list. This association is required for material reports. To enter information for each material in your system, see the Materials Tab section in the Advanced Web Interface Kit manual 332459.

  • Page 19: Reports

    Operation Reports The AWI can pull material and job information from the system and combine this information into three reports: material-based reports, job-based reports, and event-based reports. Material-Based Reports Material-based reports contain information on material used within the system. Reports can be aggregated from mul- tiple PD2K systems.
  • Page 20 Operation Material-based report columns include the following: • Total amount (in CCs) • Material ID • Sprayed VOCs (in CCs) • Material name • Total VOCs (in CCs) • Material part number • Sprayed HAPs (in CCs) • Sprayed amount (in CCs) •...
  • Page 21 Operation Job-Based Reports Job-based reports include logs of completed PD2K jobs. Select the following report filters and then click Create. • Date Range: Enter the date and time you want the report to start. The report runs from that date until the current date and time.
  • Page 22 Select the type of event (alarm, deviation, advisory, or record) to include in the report. Enter an event code to include in the report. See the Events Screen section of the ProMix PD2K Electronic Proportioner operation manual 332562 for instructions to access a list of events.
  • Page 23 Operation 3A3170A...

  • Page 24: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
