Thank you for purchasing the Autopilot ECLIPSE F90 (APE4200) Master Environmental Controller.
The ECLIPSE F90 offers integrated digital command of critical grow room conditions. Autopilot takes
full atmospheric control and lets you get back to growing. The F90 precisely controls temperature,
humidity, and CO
PPM levels in the growing area. Its three large LED displays make monitoring
2
and adjusting these environmental conditions a breeze. Three screens continuously display current
temperature, humidity and CO
user of any errors. The ECLIPSE F90 Master Environmental Controller is easy to program and operate
while showcasing total transparency of environmental conditions 24 hours a day.
The ECLIPSE F90's enclosure features four separate power outlets for external control of cooling (AC
or exhaust fan), heating, CO
These outlets feature heavy duty protective covers that prevent atmospheric moisture from
entering the device through any unused outlets. Rubber feet have also been added to the back of
the unit for added protection when mounted.
This controller's sensitive and intelligent remote combination probe features a highly accurate dual
beam NDIR CO
sensor. The probe can be placed up to 15 feet from the controller, and has been
2
designed to resist EMI/EFI from electronic ballasts. The controller itself comes equipped with wall
anchors and optional U-brackets for tent mounting.
Each ECLIPSE F90 has been pre-programmed with factory recommended settings for quick plug
and play operation. Humidity deadband, for example, is preset to 5% +/-. An adjustable Fuzzy Logic
setting is also available for use with CO
For information on additional Autopilot products please visit AutopilotControllers.com.
NOTE: After turning on the power to the unit, it will take five minutes for the sensor to warm up.
NOTE: This controller has a 14.5A maximum load. For higher amperage devices such as A/C units, it is
recommended to use a power expander.
Phillips
Screwdriver
OVERVIEW
PPM levels, and its LED lights indicate active modes and inform the
2
(regulator or generator), and humidity (humidifier or dehumidifier).
2
tank and regulator systems.
2
8' (2.5 m)
minimum
TOOLS NEEDED - (FOR OPTIONAL MOUNTING)
4
