INSTRUCTION MANUAL
APCLC8DX
COMMERCIAL LIGHTING CONTROLLERS
SPECIFICATIONS
Main Power Voltage
Main Circuit Breaker / Wire
Receptacle Type
Maximum Lighting Wattage
Maximum Relay Amperage
Operating Temperature Range
Operating Humidity Range
Minimum Relay Operations
APCLC12DX
AND
APCLC8DX
APCLC12DX
APCLC8DX
120 or 240 volts
50 amps # 6 AWG wire
8 Nema 5-15, Nema 6-15 or universal
8000 watts / 1000 watts per outlet
30 amps(x 2 relays)
32-110° F
0-99% RH non condensing
100,000 @ full load
Basic Description
The commercial 8 and 12 light controllers
from Autopilot are designed to safely
control today' s ballast. Our commercial
lighting controllers (CLC) have been
designed to activate multiple HID or
florescent lighting fixtures from a single
controller or timer.
A simple "trigger cable" is used to connect
the commercial light controller' s to a timer
or lighting controller. When the trigger
cable is powered on, one or more heavy-
duty relays inside the CLC activate and turn
on the lights connected to it.
The 8 and 12 light units have a time delay
to "soft start" each bank of 4 lights so that
start-up loads (amps) are reduced.
APCLC12DX
120 or 240 volts
60 amps # 4 AWG wire
12 Nema 5-15, Nema 6-15 or universal
12000 watts / 1000 watts per outlet
30 amps(x 3 relays)
32-110° F
0-99% RH non condensing
100,000 @ full load
