- Page 1 USER MANUAL REVOLVE F20 (Repeat Cycle and Light Combo Timer ) APE2200 AutopilotControllers.com...
- Page 2 AutopilotControllers.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS OVERVIEW PARTS LIST - (WHAT’S IN THE BOX) LED DISPLAY & CONTROL SURFACE OPERATING INSTRUCTIONS LIGHT ON/OFF SETTING RECYCLE TIMER SETTING MAXIMUM TEMPERATURE SETTING RECYCLE OUTPUT NIGHT OUTPUT MOUNTING INSTRUCTIONS SECURE UNIT TO A WALL SECURE UNIT TO A GROW TENT GENERAL WARNINGS SPECIFICATIONS WARRANTY... -
Page 4: Overview
REVOLVE F20 has four outlets. One outlet is equipped with a cycle timer designed to control a pump or any other cycling device; two outlets control daytime devices such as lights and light movers;... -
Page 5: Parts List - (What's In The Box)
PARTS LIST - (WHAT’S IN THE BOX) A - Controller Unit D - Power Cord B - Sensor Unit E - Mounting Hardware(for walls) C - Sensor Cord F - Mounting Hardware (for grow tents) -
Page 6: Led Display & Control Surface
LED DISPLAY & CONTROL SURFACE Turn light ON/OFF setting LIGHT 1 OUTPUT LIGHT 2 OUTPUT TEMP setting RECYCLE TIMER SETTING RECYCLE OUTPUT NIGHT OUTPUT POWER INPUT ON/OFF BREAKER FUNCTION KNOBS Click knob, turn to set, press STATUS again to confirm Press both knobs for 3 seconds, set clock... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS LIGHT ON/OFF SETTING NOTE: The unit’s clock uses 24-hour military time format and not a.m./p.m. LIGHT ON TIME: Click the LIGHT ON TIME knob and turn to set your desired on time point, e.g. turn light on at 06:00 (6:00 a.m.). Click the LIGHT ON TIME knob again to save the setting. LIGHT OFF TIME: Set light off time the same way, using the LIGHT OFF TIME knob. -
Page 8: Mounting Instructions
MOUNTING INSTRUCTIONS SECURE UNIT TO A WALL Secure the controller to the wall using the included mounting clips and screws. SECURE UNIT TO A GROW TENT Secure the controller to one of the grow tent’s vertical support rods with the included U-bolt brackets. -
Page 9: General Warnings
GENERAL WARNINGS 1. Save the instructions. These safety and operating instructions must be kept in a safe place for future reference. 2. Heed all warnings. All warnings on this product and in the instructions must be observed closely. 3. Follow all instructions. All operating instructions must be followed. 4. -
Page 10: Specifications
SPECIFICATIONS Max amperage 14.5A @ 120VAC 60 Hz Power cord length 6.5' (2 m) Sensor cord length 15' (4.5 m) Lighting timer 24-hour timeclock Light re-fire setting 3-15 minutes Max temp setting Adjustable 85-115°F (30-46°C) Temperature accuracy ±2°F/1°C Recycling ON timer range 1 second to 24 hours Recycling OFF timer range 1 second to 24 hours... -
Page 12: Warranty
The purchase date is based on your original sales receipt. precise climate control precise climate control Thank you for choosing Autopilot by Hydrofarm. For further information about Autopilot products, videos, and technical information, please visit AutopilotControllers.com ADDITIONAL LANGUAGES OF THESE INSTRUCTIONS CAN BE FOUND AT Hydrofarm.com...
