Controls, features and connections

(1) TURNTABLE MOTOR SWITCH
(2) AMPLIFIER ON/OFF SWITCH
(3) REMOTE CONTROL
(4) INPUT SELECTOR, VOLUME CONTROL
(5) PLATTER
(6) DRIVE BELT
(7) STEPPED DRIVE PULLEY
(8) TONEARM COUNTERWEIGHT
(9) TONEARM TUBE
(10) TONEARM REST AND REMOVABLE TRANSPORT LOCK
(11) TONEARM LIFT LEVER
(12) HEADSHELL WITH FINGER LIFT
(13) TURNTABLE DISPLAY
(14) EARTH CONNECTION
(15) LINE OUTPUT
(16) PHONO OUTPUT
(17) LINE INPUT
(18) BLUETOOTH ANTENE
(19) SPEAKERS OUTPUT
(20) POWER SUPPLY SOCKET
(21) LID
(22) LID HINGE
(23) HINGE FASTENERS
POWER SUPPLY (NOT SHOWN) *
