- Page 1 All manuals and user guides at all-guides.com Juke Box Setup Guide Please read before unpacking!
- Page 2 All manuals and user guides at all-guides.com Setup Guide for Juke Box E & S2...
-
Page 3: Get Started
All manuals and user guides at all-guides.com Get started: - Make sure you have enough space to unpack your turntable. - Make sure to unpack it in a clean enviroment. - Do not throw packaging away. Important for warranty! More information about the product in the manual. - Page 4 All manuals and user guides at all-guides.com Open the carton and unpack all items from ac- cessory bag. a) Stylus pressure gauge b) Batteries for remote control c) Drive Belt d) Fabric gloves e) Adapter for 7“singles / allen key for counterweight setting f) Weight for ultra light cartridges g) Bluetooth antenna...
- Page 5 All manuals and user guides at all-guides.com...
- Page 6 All manuals and user guides at all-guides.com Remove dust cover carton from the box.
- Page 7 All manuals and user guides at all-guides.com Carefully remove the turntable protection insert.
- Page 8 All manuals and user guides at all-guides.com Lift the wrapped turntable out of the box.
- Page 9 All manuals and user guides at all-guides.com Unpack the power supply.
- Page 10 All manuals and user guides at all-guides.com Carefully remove the protection covering. Tonearm is fragile!
- Page 11 All manuals and user guides at all-guides.com Remove the platter protection.
- Page 12 All manuals and user guides at all-guides.com Put the drive belt on the pulley and platter. Start with the pulley! Small pulley- 33 RPM Big pulley - 45 RPM Important: Make sure to have clean hands when touching the belt. Dirt on the belt can cause it to slip.
- Page 13 All manuals and user guides at all-guides.com Install the Bluetooth antenna.
- Page 14 All manuals and user guides at all-guides.com Unpack dust cover and put it on the turntable.
- Page 15 All manuals and user guides at all-guides.com How to correctly position your speakers. For enjoying a perfect stereo image: If the speakers are two meters apart from each other, the listener should sit at a maximum position of three meters, but no futher. Tweeter level For longer distances please use this 2:3 rule.
- Page 16 All manuals and user guides at all-guides.com Plug speaker cables into the turntable / connect the power cable. Speaker cables Power cable left and right speaker channel Please note: „L“ out is going to the speaker that you see on your left when you’re looking at your system.
- Page 17 All manuals and user guides at all-guides.com Remove tonearm twist tie.
- Page 18 All manuals and user guides at all-guides.com Turning on the Juke Box. Switching ON and To switch on from standby or to (turntable motor) standby (amplifier)
- Page 19 All manuals and user guides at all-guides.com Control of the unit using the knob on the front. Standby Press the knob for 3 seconds to turn the unit on. Input selector Briefly press the knob to switch between Bluetooth > Turntable > Line In Volume Adjust volume by turning the knob.
- Page 20 All manuals and user guides at all-guides.com Remove the needle protection cover. Beware of breaking the needle!
- Page 21 All manuals and user guides at all-guides.com Play your records Make sure the tonearm lift lever is in an upright position.
- Page 22 All manuals and user guides at all-guides.com Move the tonearm over the lead in groove.
- Page 23 All manuals and user guides at all-guides.com Move the tonearm lever down.
-
Page 24: Enjoy Your Music
All manuals and user guides at all-guides.com Enjoy your music!
