Page 1: User Manual
TrangoLINK-10 Point to Point Wireless Ethernet Bridge USER MANUAL June 11, 2003 -DRAFT- Rev. A for Firmware ver. 1.0... -
Page 2: Table Of Contents
Table of Contents Trango Table of Contents Preface .................................. iii FCC Information............................... iii Warranty Information ............................iii Chapter 1 Welcome!............................1 Getting to Know Your Radio..........................1 Contents ................................. 1 Ethernet and Serial Ports ..........................2 Antennas ................................ 2 MU/RU Operational Overview.......................... 2 Chapter 2 Getting Started .......................... -
Page 3: Preface
Command Set Summary FCC Information Preface This manual covers basic configuration and installation of the TrangoLINK-10 Wireless Broadband System and applies to the following radio part numbers: P5830S-MU Master Unit with internal sector al patch antenna P5830S-RU Remote Unit with internal patch antenna Also available is the TrangoLINK-10-EXT, which does not include an internal antenna. -
Page 4: Welcome
TrangoLINK -10 is a point-to-point (PtP) system which provides network connectivity at speeds up to 10 Mbps with a range of 40 miles depending on antenna configuration. TrangoLINK-10 is unique in that it can operate in either the 5.8 GHz ISM band or the 5.3 GHz U-NII band. In this document and within the radio configuration itself, the designators of “ISM”... -
Page 5: Ethernet And Serial Ports
Command Set Summary MU/RU Operational Overview Figure 0-2 Back of Radio Showing where MAC address can be Found MUs and RUs look identical. The only way to tell them apart is by the model number printed on the backside product label. This label also contains the MAC ID of the radio as well as the serial #. -
Page 6: Chapter 2 Getting Started
Command Set Summary Connections and Power Chapter 2 Getting Started First unpack your MU and RU. It is recommended to first provision and test the radios on the bench before deploying in the field. This is a particularly useful exercise to the novice user. Connections and Power Connection and powering of radios is the same for MUs and RUs. -
Page 7: Basic Configuration - Concepts And Tools
Basic Configuration - Concepts and Tools Basic Configuration - Concepts and Tools The TrangoLINK-10 can be configured using either the Command Line Interface (CLI) or the Web Browser (HTTP) interface. Although both methods are comprehensive and powerful, the CLI method provides slightly more functionality. -
Page 8: Browser Interface
Command Set Summary Basic Configuration - Concepts and Tools Telnet Open a command prompt (DOS) session on your PC. Open a Telnet session by typing telnet [ip address of radio] Example: C:>telnet 192.168.100.100 Note: All Trango radios (MU and RU) come factory pre-configured with a default IP address 192.168.100.100. You will be greeted with current hardware and firmware information and prompted for a password. - Page 9 Command Set Summary Basic Configuration - Concepts and Tools Type the password (default trango) and continue. This will bring up the radio’s system information page. The Browser Interface features useful Help pages which explain all listed parameters. To access the help pages click on the Help link.
-
Page 10: Master Unit Basic System Information
Command Set Summary Master Unit Basic System Information Master Unit Basic System Information Logon to the MU and the System Configuration page with info and status appears. The equivalent command for the CLI is sysinfo. Many of these parameters can be changed by the user. Basic configuration can be performed from the Configuration page, and RF related parameters are configured through the Advanced Setup page.. -
Page 11: Figure 0-5 Reference Table Of Basic Mu System Information
Command Set Summary Master Unit Basic System Information Figure 0-5 Reference Table of Basic MU System Information MU SYSTEM INFORMATION PARAMETERS AND RELATED COMMANDS Parameter Description Related CLI Command Device ID Mac ID of MU Remote ID Mac ID of the RU that is going to be associated to the MU. -
Page 12: Remote Unit Basic System Information
Command Set Summary Remote Unit Basic System Information Remote Unit Basic System Information Logon to the RU (while it is in opmode “OFF”) and the System Information page will appear. In the CLI, type the command sysinfo to receive a comprehensive snapshot of the system’s configuration info and status. Many of these parameters can be changed by the user. -
Page 13: Chapter 3 Establishing A Wireless Link
Command Set Summary Procedure to Establish Wireless Link Chapter 3 Establishing a Wireless Link This section describes how to establish a wireless link between MU and RU, using the command line interface. Procedure to Establish Wireless Link In order to establish a wireless link, the following parameters must be set. The Remote ID, the MAC ID of the RU, must be set in the MU. -
Page 14: Association Concept (Mu To Ru Communications)
Command Set Summary Basic Diagnostics At this point the MU will begin actively searching for the RU. Once the RU is detected, the authentication and association process will begin. The RU by default is ready to establish a link. Only the RF channel and polarization need to be chosen. - Page 15 Command Set Summary Basic Diagnostics Remote: The bottom left side of any page in the Browser Interface, under the heading Remote, shows the connection status of the RU. It will also show the Relative Signal Strength (RSSI) of the link RF Link Loopback Test: Sends 1600 byte packets to the RU at 50 millisecond intervals over the time specified and reports the success rate of the packets in bytes.
-
Page 16: Chapter 4 Deployment
Command Set Summary Site Selection Chapter 4 Deployment Once you are familiar with the basic operation of the radios you are ready for deployment in the field. The deployment process consists of the following steps: ?? Site Selection ?? Site survey at MU and RU sites. ?? MU installation ?? RU installation and antenna alignment ?? Link test... -
Page 17: Channel Planning
Command Set Summary Channel Planning Channel Planning For installations involving co-location of MU’s, channel planning is of paramount importance. For maximum MU co- location quantities, it is important to assign frequencies of maximum spacing and alternating polarizations for adjacent MUs. Use of the 5.3 spectrum U-NII band as well as the 5.8 spectrum ISM band will allow maximum co-location potential. -
Page 18: Figure 0-8 Mounting Hardware Assembly
Command Set Summary Installation Figure 0-8 Mounting Hardware Assembly Trango Broadband Wireless — User Manual TrangoLINK Rev. A for F/W Ver. 1.0 Page 15... -
Page 19: Cabling And Weather Considerations
Command Set Summary Installation Figure 0-9 Mounting Options 20.00 ° UP/DOWN TILT MAX INVERTED BRACKET .50" - 3.00" DIAM. MAST SMALL DIAM. MAST FOR MAST SIZES SMALLER THAN 2.00" BRACKET MUST BE INVERTED (SEE DETAIL 'A' BELOW) POLE MOUNT 40.00 ° UP/DOWN TILT MAX 90.00 °... -
Page 20: Ru Installation And Antenna Alignment
Command Set Summary RU Installation and Antenna Alignment The cable ports are purposely located at the bottom of the radio to minimize the risk of water intrusion. Do not mount the radios upside down. Note: The J-Box is not a weatherized device and must be located either indoors or in a weather-protected cabinet. Note: It is important to provide strain relief and drip loop for STP Cat-5 cables. -
Page 21: Chapter 5 Management
Command Set Summary RU Management Chapter 5 Management In the TrangoLINK system the MU controls most functions of its associated RU. For this reason it is important to consider that you will manage your TrangoLINK system primarily through the MU. Network management can be performed by three methods ?? Browser Interface ?? CLI... -
Page 22: Snmp Setup
Command Set Summary SNMP ?? aptrafficEthRxAvgThroughputLog – Average payload data throughput (in Kbits/sec) received on the Ethernet port over the period of 1 minute. ?? aptrafficEthTxAvgThroughputLog – Average payload data throughput (in Kbits/sec) transmitted on the Ethernet port over a period of 1 minute. ?? aptrafficRfRxAvgThroughputLog –... - Page 23 Command Set Summary SNMP For all the set operations, set object SaveAndActivate at apsystem-apsystemInfo to write the information to FLASH. Trango Broadband Wireless — User Manual TrangoLINK Rev. A for F/W Ver. 1.0 Page 20...
-
Page 24: Command Set Summary
Command Set Summary SNMP Command Set Summary ?? OFF = opmode off, ON = opmode on ?? s = serial, e = Ethernet ?? M = Master Only, R = Remote Only ?? + It may not work properly through http’s command console. ?? good for Master/Remote 1p0 Command Description... - Page 25 Command Set Summary SNMP <new gateway> re ping ping Remote Radio re reboot reboot Remote Radio re speedtest [<pkt len> <file size>] perform speedtest default: <pkt len> = 64..1760 bytes <pkt len> = 1760 bytes <file size> = 10..100 Mbytes <file size>...
- Page 26 Command Set Summary SNMP It must be in -45 to -75 and +5 dB higher than RF Rx Threshold set snmpcomm [<read|write>] display or assign snmp community string set telnetport [<port #>] specify telnet port, <port #> = 1..65534 default = 23 ssrssi <ch #>...
-
Page 27: Chapter 6 Specifications
Command Set Summary SNMP Chapter 6 Specifications All specifications apply to P5830S-R and P5830S-M unless otherwise noted. Radio Parameters High Band (ISM) Low Band (U-NII ) Frequency of Operation 5725 MHz to 5850 MHz 5250 MHz to 5350 MHz 6 non-overlapping channels 5 non-overlapping channels Antenna Gain Internal Antenna... -
Page 28: Chapter 7 Glossary
Command Set Summary SNMP Chapter 7 Glossary Antenna Gain The gain of an antenna is a measure of the antenna’s ability to direct or focus radio energy over a region of space. High gain antennas have a more focused radiation pattern in a specific direction. AP Access Point. - Page 29 Command Set Summary SNMP IEEE Institute of Electrical and Electronic Engineers. A professional society serving electrical engineers through its publications, conferences, and standards development activities. The body responsible for the Ethernet 802.3 and wireless LAN 802.11 specifications. Infrastructure The wired Ethernet network. IP Address The Internet Protocol (IP) address of a station, or the layer three address used in routing packets.
