TrangoLINK-10-EXT Professional Installation Guide Overview This manual covers basic configuration and installation of the TrangoLINK-10-EXT system which consists of two radios, P5830S-MU-EXT (Master Unit) and P5830S-RU-EXT (Remote Unit). Since these devices require manual maximum power limit settings (for 5.25-5.35 GHz U-NII band operation only), they are classified by the FCC as a professional install devices.
General Information Contents Each TrangoLINK-10-EXT kit comes equipped with a Master Unit (MU) and Remote Unit (RU), two power-over- Ethernet (PoE) J-Boxes, two AC adapters, and two mounting kits. The MAC Address and Serial # are printed on a label on the back of the radio.
Page 4
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide Antenna Model Antenna Gain (incl/cable loss) Radio Max power setting AD5830-23-D +24 dBi +6 dBm AD5830-24-D +24 dBi +6 dBm SPD3-5.2 +30 dBi 0 dBm Note: that in all cases, Antenna Gain – cable loss + Radio Max Power Setting is 30 dBm. Once set, the power leveling feature will still operate normally, but the maximum EIRP will never exceed 1 watt (30 dBm).
Page 5
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide Radio Hardware Installation The P5830S-MU-EXT and P5830S-RU-EXT may be installed on a pole or a flat surface per the drawings below: WALL MOUNTING POLE MOUNTING TO ANTENNA TO ANTENNA BRACKETS (SUPPLIED) BOLTS FOR MOUNTING TO WALL NOT SUPPLIED Radios should always be mounted with Ethernet and RJ11 ports at the bottom.
Page 6
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide AD5830-24-D DSS STYLE ANTENNA See diagram below for proper installation of the AD5830-24-D These antennas are designed primarily for low rise building installations only. Do not install in an area where high (>70 mph) winds are expected. NOTE: Optimal alignment of this dish (to radio at horizon) is 20°...
Page 7
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide AD5830-23-D PANEL ANTENNA To install the AD5830-23-D Panel antenna please see the drawing below: 11° 27° 25° 61° WALL MOUNT BRACKET POLE MOUNTING WALL MOUNTING A-9014 HEAT SHRINK HERE AFTER TIGHTENING CONNECTOR 2X CA-9023 4X ATTACH WALL BRACKET WITH POLE MOUNT("V") BRACKET...
Page 8
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide Model No. PE34361-48 46” REVERSE POLARITY SMA MALE TO STANDARD N MALE See the Radiowaves SPD3-5.2 User’s Manual for detailed hardware installation instructions. Remote Unit Antenna Alignment To align the RU antenna for optimal performance, follow the procedure outlined in the TrangoLINK-10 User Manual.
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide Specifications Radio Transmit Specifications Frequencies: Storable Channels: 30 memory locations Channel spacing: Low Band: 5.260 to 5.340 GHz in 1 MHz channel increments High Band: 5.736 to 5.836 GHz in 1 MHz channel increments Default Channels- Channel 1: 5.736 GHz...
Page 10
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide Power is supplied on Ethernet cable using junction box provided with up to 330 foot 24 AWG STP cable. Current Cons.: 575 mA in transmit mode at max power using 20 V standard adapter (11.5W)
Page 11
RU Antenna Alignment TrangoLINK-10-EXT Professional Installation Guide Polarization Vertical, horizontal electronically selectable Frequency 5.2 to 5.9 GHz Gain +24 dBi Azimuth Beamwidth 9 degrees Elevation Beamwidth 9 degrees Mount Heavy Duty Universal Mount. Radio Waves SPD3-5.2 Parabolic Dish for P5830S-SU-EXT Type Parabolic Prime Focus 36"...
