VENT-FREE GAS
FIREPLACE INSERT
OWNER'S OPERATION AND
INSTALLATION MANUAL
MODEL FDI32R
PFS
®
US
Advertisement
Table of Contents
Related Manuals for Duluth Forge FDI32R
Summary of Contents for Duluth Forge FDI32R
- Page 1 VENT-FREE GAS FIREPLACE INSERT OWNER’S OPERATION AND INSTALLATION MANUAL MODEL FDI32R ® Visit us online at www.FACTORYBUYSDIRECT.com for a list of mantels used with this product. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ............3 Installation ..........9 Specifications ..........4 Operation ..........20 Qualified Installing Agency ......5 Inspecting Burners........24 Product Features ........5 Care And Maintenance ......25 Local Codes..........5 Troubleshooting ........26 Unpacking..........6 Replacement Parts ........ -
Page 3: Safety
SAFETY IMPORTANT: Read this owner’s WARNING: Any change to manual carefully and completely this fireplace or its controls can before trying to assemble, op- be dangerous. erate, or service this heater. Improper use of this heater can WARNING: Do not allow fans cause serious injury or death to blow directly into fireplace. -
Page 4: Specifications
Poor combustion and higher levels of carbon monoxide may result. SPECIFICATIONS Model FDI32R Gas Type Natural Gas Propane Gas Ignition Piezo Ignitor... -
Page 5: Qualified Installing Agency
QUALIFIED INSTALLING AGENCY Only a qualified agency should install and a) Installing, testing, or replacing gas piping replace gas piping, gas utilization equipment or accessories, and repair and equipment ser- b) Connecting, installing, testing, repairing, vicing. The term “qualified agency” means any or servicing equipment;... -
Page 6: Unpacking
UNPACKING 1. Remove top inner pack. 7. Remove log set by cutting plastic ties. 2. Tilt carton so that heater is upright. 8. Carefully unwrap log. 3. Remove protective side packaging. 9. Check for any shipping damage. If heater or log is damaged, promptly inform your 4. -
Page 7: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: This heater shall WARNING: This heater shall not be installed in a confined space not be installed in a room or or unusually tight construction space unless the required vol- unless provisions are provided ume of indoor combustion air for adequate combustion and is provided by the method de-... -
Page 8: Ventilation Air From Inside Building
AIR FOR COMBUSTION AND VENTILATION VENTILATION AIR Ventilation Air From Inside Building This fresh air would come from an adjoining 1 and 2, Figure 2). You can also remove door unconfined space. When ventilating to an into adjoining room (see option 3, Figure 2). adjoining unconfined space, you must provide Follow the National Fuel Gas Code, ANSI two permanent openings: one within 12"... -
Page 9: Installation
INSTALLATION IMPORTANT: Vent-free heaters add moisture NOTICE: This heater is intended to the air. Although this is beneficial, installing for use as supplemental heat. heater in rooms without enough ventilation air Use this heater along with your may cause mildew to form too much moisture. primary heating system. - Page 10 INSTALLATION GAS SELECTION Insert Gas Fitting Insert Gas Fitting This appliance is factory for Propane/LP Gas for Natural Gas preset for propane/LP gas. No changes are required for connecting to propane/LP. Only a qualified installer or service technician can perform gas selec- tion and connecting to gas supply.
- Page 11 INSTALLATION 2. Apply thread sealant to the threads on Use only the cap supplied on the the connection fitting. While pushing in, regulator. Do not use an off the rotate the fitting clockwise until the threads shelf pipe plug. This can damage engage the regulator.
- Page 12 INSTALLATION BUILT-IN FIREPLACE INSTALLATION WARNING: Do not allow any combustible materials to overlap the firebox front. WARNING: Do not allow combustible or noncombustible 3/4" Clearance to Facia materials to cover any necessary " Clearance to Sides, Back and Top openings like louvered slots. "...
-
Page 13: Installing Hood
INSTALLATION 3. Attach gas line to fireplace gas regulator. See Connecting to Gas Supply, page 14. 4. Check all gas connections for leaks. See Checking Gas Connections, page 16. " IMPORTANT: When finishing your firebox, combustible materials such as wall board, gypsum board, sheet rock, drywall, plywood, etc, must have 1/2"... - Page 14 INSTALLATION CONNECTING TO GAS SUPPLY WARNING: A qualified ser- CAUTION: For propane/ vice technician must connect LP gas, never connect heater directly to the gas supply. This heater to gas supply. Follow all heater requires an external local codes. regulator (not supplied). Install WARNING: This appliance the external regulator between requires a 3/8"...
- Page 15 INSTALLATION Apply pipe joint sealant lightly to male threads. as shown in Figure 13. Pointing the vent down This will prevent excess sealant from going protects it from freezing rain or sleet. into pipe. Excess sealant in pipe could result For both gas types, install sediment trap in in clogged heater valves.
-
Page 16: Checking Gas Connections
INSTALLATION CHECKING GAS CONNECTIONS 2. Pressurize supply piping system by either 2. Pressurize supply piping system by either WARNING: Test all gas piping opening propane/LP supply tank valve opening propane/LP supply tank valve and connections for leaks after for propane/LP gas or opening main gas for propane/LP gas or opening main gas installing or servicing. - Page 17 INSTALLATION 4. Check all joints from equipment shutoff 6. Light heater (see Lighting Instructions on valve to control valve (see Figure 16 or page 20). Check all other internal joints 17, page 16). Apply a noncorrosive leak for leaks. detection fluid to all joints. Bubbles form- 7.
- Page 18 INSTALLATION INSTALLING LOGS Each log is marked with a number. This WARNING: Failure to posi- number will help you to identify the logs when tion the parts in accordance installing. with these diagrams or failure After installing logs, add decorative cinders around the grate base, do not place any to use only parts specifically decorative cinders on logs or burner.
- Page 19 INSTALLATION INSTALLING BATTERIES Receiver and Remote Control CAUTION: Do not mix old and Batteries are required in both the Remote new batteries. Do not mix alka- Control (Transmitter) (2 AAA size) and Re- ceiver (4 AA size) (see Figure 23). line, standard (carbon - zinc), or Note: Be sure batteries are placed correctly.
-
Page 20: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING not use any phone in your building. WARNING: If you do not fol- • Immediately call your gas supplier low these instructions exactly, a from a neighbor’s phone. Follow the fire or explosion may result caus- gas supplier’s instructions. -
Page 21: To Turn Off Gas To Appliance
OPERATION 6. With control knob pressed in, push 9. Turn control knob counterclockwise down and release ignitor button. This to the ON position. The main burner will light pilot. The pilot is attached should light. to the burner. If needed, keep press- 10. -
Page 22: Remote Control System
OPERATION REMOTE CONTROL SYSTEM Programming the Remote and Receiver Key Settings ON - Operates unit to on position, manually The remote and receiver must be “learned” to one another. operated solenoid ON. OFF - Operates unit to off position, manually To prepare the receiver box for learning, use a pen or small screwdriver to gently press operated solenoid OFF. - Page 23 OPERATION Setting°F/°C Scale 2. Press and hold the SET key until the de- The factory setting for temperature is °F. To sired set temperature is reached. The LCD change this setting to °C, press the ON key screen set numbers will increase from 45° and the OFF key on the remote control at the to 99°...
-
Page 24: Inspecting Burners
INSPECTING BURNERS IMPORTANT: Owner’s should check pilot flame pattern and burner flame pattern often. Incorrect flame patterns indicate the need for cleaning (see Care and Maintenance, page 25) or service. WARNING: Only a qualified service person should service and repair heater. This includes maintenance requiring replacement or alteration of components. -
Page 25: Care And Maintenance
CARE AND MAINTENANCE WARNING: Turn off heater and let cool before servicing. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service techni- cian. -
Page 26: Troubleshooting
CARE AND MAINTENANCE CABINET Air Passageways Exterior Use a vacuum cleaner or pressurized air to • Use a soft cloth dampened with a mild soap clean. and water mixture. • Wipe the cabinet to remove dust. LOGS • If you remove logs for cleaning, refer to Installing Logs, page 18, to properly replace logs. •... - Page 27 TROUBLESHOOTING The entire gas delivery piping including connec- the correct flame pattern as illustrated on page tions inside the heater should be leak tested by 22. All flame patterns should be safely inside the the qualified installer. After leak testing the quali- product.
- Page 28 TROUBLESHOOTING Problem Possible Cause Corrective Action Burner(s) does not light 1. Burner orifice is clogged. 1. Clean burner orifice (see after ODS/pilot is lit Care and Maintenance, page 25) or replace burner orifice. 2. Burner orifice diameter is too 2. Replace burner orifice. small.
-
Page 29: Replacement Parts
TROUBLESHOOTING Problem Possible Cause Corrective Action White powder residue 1. When heated, the vapors 1. Turn heater off when using forming within burner from furniture polish, wax, furniture polish, wax, carpet box or on adjacent walls carpet cleaners, etc., turn cleaner or similar products. -
Page 30: Parts
PARTS MODEL FDI32R TEMP 22 16 www.factorybuysdirect.com 200245-01A... -
Page 31: Service Hints
PARTS MODEL FDI32R This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 29 of this manual. ITEM PART # DESCRIPTION FB32D600-02 Burner Assembly ND0310A-400-P ODS Pilot ML073-04 Ignitor Cable... -
Page 32: Warranty
WARRANTY KEEP THIS WARRANTY Model _______________________________ Serial No. ____________________________ Date Purchased _______________________ Keep receipt for warranty verification. REGISTER YOUR PRODUCT AT WWW.FACTORYBUYSDIRECT.COM FACTORY BUYS DIRECT LIMITED WARRANTIES New Products Standard Warranty: Factory Buys Direct warrants this new product and any parts thereof to be free from defects in material and workmanship for a period of one (1) year from the date of first purchase from an authorized dealer provided the product has been installed, maintained and operated in accordance with Factory Buys Direct’s warnings and instructions.
