Page 1
ELECTRIC FIREPLACE OWNER’S MANUAL MODELS EL1346C 4001358 WARNING: If the information in this manual is not followed exactly, a fire or electrical shock may result causing property damage, personal injury or loss of life. INSTALLER: Leave this manual with the appliance.
TABLE OF CONTENTS Quick Reference Guide ......2 Control Panel Operation ......7 Important Instructions ........ 2 Remote Control Operation......7 Specifications ..........4 Care and Maintenance ......8 Product Dimensions ........4 Troubleshooting ......... 9 Installation ..........5 Warranty ..........10 Operating Instructions .......
Page 3
IMPORTANT INSTRUCTIONS CONT. 3. Extreme caution is necessary when any heater is used by or near children or individuals and whenever the unit is left operating and unattended. 4. Always unplug the electric fireplace when not in use. 5. Do not operate any unit with a damaged electrical cord or plug, or if the heater has malfunctioned, or if the electric fireplace has been dropped or damaged in any manner.
20. When transporting or storing the unit and electrical cord, keep in a dry place, free from excessive vibration and store so as to avoid damage. WARNING: In order to avoid overheating, do not cover the heater. SPECIFICATIONS Model EL1346C Rated Voltage AC 120V, 60Hz Rated Power 1,350W...
INSTALLATION NOTE: A 15Amp/120Volt alternating current (VAC) circuit is required. A dedi- cated circuit is preferred but not essential in all cases. A dedicated circuit will be required if, after installation, the circuit breaker trips or fuse blows on a regular basis when the heater is operating.
OPERATING INSTRUCTIONS NOTE: When you first turn the heater on, it may emit a slight but harmless odor. This odor results from certain oils or greases being heated as the appliance is used for the first time. This odor is perfectly safe and will stop shortly, it will not reoccur after the first operation of the appliance.
OPERATING INSTRUCTIONS CONT. Button (F): °C / °F Push button F to change the heat readout settings. °C for Celsius, °F for Fahr- enheit. Corresponding icon will be shown on front screen after the button is pressed. REMOTE CONTROL OPERATION: This heater includes a remote control.
OPERATING INSTRUCTIONS CONT. Button (N): Dimmer (Brightness Increase) Push button N to increase the flame effect. Button (I): Dimmer (Background Light Decrease) Push button I to decrease background light, press once and the background light decreases one level. Button (O): Dimmer (Background Light Increase) Push button O to increase background light, press once and the background light increases one level.
CARE AND MAINTENANCE CONT. GLASS CLEANING The glass is cleaned in the factory during the assembly operation. During ship- ment, installation, handling, etc., the clear door may collect dust particles; these can be removed by dusting lightly with a clean dry cloth. To remove fingerprints or other marks, the clear door can be cleaned with a damp cloth.
WARRANTY KEEP THIS WARRANTY Model _______________________________ Serial No. ____________________________ Date Purchased _______________________ Keep receipt for warranty verification. REGISTER YOUR PRODUCT AT WWW.FACTORYBUYSDIRECT.COM FACTORY BUYS DIRECT LIMITED WARRANTIES New Products Standard Warranty: Factory Buys Direct warrants this new product and any parts thereof to be free from defects in material and workmanship for a period of one (1) year from the date of first purchase from an authorized dealer provided the product has been installed, maintained and operated in accordance with Factory Buys Direct’s warnings and instructions.
