Parts List
First things first -- make sure have all of the necessary components in your
SimpliciKey package.
1 interior lock 1 interior plate
1 exterior lock
2 remote control
2 keys
keyfobs
2 short bolts 2 long
wood screws
2 long bolts
2 strike wood 2 short wood
screws screws
1 strike plate 1 deadbolt lock
1 reinforcement 1 strike box
plate
2

LOCK INSTALLATION INSTRUCTIONS

1. Remove Existing Deadbolt

First, remove the two interior screws
securing the lock.
Next, remove the interior and
exterior lock components.
Finally, take out the existing deadbolt
slide assembly.

2. Check Cutout Size

Critical Point
Stop to measure the cutouts for the lock
components. If the main cutout is 2-1/8 inches in
diameter, and latch cutout is 1 inch, you're ready
to go. If not, you may need to use the Advanced
Guide to help you adjust your door.
2" Thickness Max
1"
2 1/8"
