Installation Instructions

4500 Series Electric Strike
Product Components
4500 Electric Strike Body
1
Deadlatch Tab for Mortise locksets
2
Screws for Deadlatch or Filler Tabs
3
Filler Tab for Cylindrical Locksets
4
7
6
Diagram 1: Electrical Specifications
ELECTRICAL RATINGS FOR SOLENOID
Resistance in Ohms
Amps
Solenoids are rated at +/- 10% indicated value.
*10% max duty cycle (2 min. max on time)
ASSA ABLOY, the global leader
in door opening solutions
1
CONTINUOUS DUTY
INTERMITTENT DUTY*
12VDC
24VDC
12-16VAC
24VAC
50
200
50
.24
.12
.24-.32
Trim Enhancer (with screws)
5
12 & 24 Volt Pigtails
6
#12-24 Mounting Screws
7
2
4
5
MINIMUM WIRE GAUGE REQUIREMENTS
200
200 feet or less
.12
200 - 300 feet
300 - 400 feet
HES, Inc.
22630 N. 17th Ave.
Phoenix, AZ 85027
800-626-7590
www.hesinnovations.com
3
SOLENOID VOLTAGE
12VDC
24VDC
18 gauge
18 gauge
16 gauge
18 gauge
14 gauge
16 gauge
1
