- Page 1 Stanley MB/XP3025 HYDRAULIC BREAKER Parts Manual Part Number PMMB/XP3025XENG.B17...
-
Page 2: Table Of Contents
• Mode of delivery (air mail etc.) It is important that you use only genuine Stanley spare • Required delivery date parts, to ensure easy operation maintenance and re- •... - Page 3 PARTS Parts Manual MB/XP3025 3...
-
Page 4: Housing Unit
HOUSING UNIT 4 Parts Manual MB/X3025... - Page 5 HOUSING UNIT Item Description Part no. Specification Note Housing 80628 78603 Buffer 77770 Rubber plug 78604 Hex. screw 76905 M24x110-12.9 ISO 4014 Washer 76906 25 ISO 7416 Lock nut 76907 M24-12 DIN 985 Plug 77716 Rubber plug 78609 Seal 78610 Wear plate 78611 Lifting eye...
-
Page 6: Accumulator
ACCUMULATOR Item Description Part no. Specification Note Accumulator (incl. parts 2-11) 78615 Accumulator bottom 78616 Accumulator cover 78617 Membrane 77779 Accumulator screw 77780 Filling plug 76921 Seal 76924 D114 Shield plug 76922 Usit-ring 76846 8-13.9-1 Parallel pin 77781 10m6x24 DIN 6325 O-ring 76844 Accumulator screw... -
Page 7: Main Valve
MAIN VALVE Item Description Part no. Specification Note Main valve bushing 78619 Main spool 78620 Spool 78621 Spool 77786 Cover 78622 Cover 78623 O-ring 77789 D105 Seal 77790 D110 Hex. screw 76933 M16x35-8.8 ISO 4017 Lock washer 76852 M16 NORD-LOCK (*) included in seal set Parts Manual MB/XP3025 7... -
Page 8: Restrictor Valve
RESTRICTOR VALVE 8 Parts Manual MB/X3025... - Page 9 RESTRICTOR VALVE Item Description Part no. Specification Note Restrictor valve (incl. parts 2-10) 78624 Cover 76935 Spool 77793 Valve housing 78625 Spring 76938 O-ring 76939 O-ring 76940 O-ring 76941 Shim plate 76861 S=0.5 Shim plate 76860 Hex. screw 76933 M16x35-8.8 ISO 4017 Lock washer 76852 M16 NORD-LOCK...
-
Page 10: Pressure Control Valve
PRESSURE CONTROL VALVE 10 Parts Manual MB/X3025... - Page 11 PRESSURE CONTROL VALVE Item Description Part no. Specification Note Pressure control valve (incl parts 2-16) 78626 Cover 77796 Valve housing 77797 Spool 78627 Guide 77799 Spool 78062 Spring guide 78063 Spring 76950 Shim plate 76951 S=0.5 Shim plate 76952 Shim plate 76953 S=0.75 Plug...
-
Page 12: Tie Rods
TIE RODS Item Description Part no. Specification Note Tie rod set (incl. parts 2-6) 78629 Vibration dampening element 78630 Cable tie 76962 Rubber ring 78631 Lock plate 78632 Spacer 78633 12 Parts Manual MB/X3025... -
Page 13: Body Parts
BODY PARTS Parts Manual MB/XP3025 13... - Page 14 BODY PARTS Item Description Part no. Specification Note Valve body (incl parts. 2-10) 78634 Breather (incl part 11) 78075 Flange plug 76859 R3/4 Flange plug 76847 R3/8 Flange plug 76969 R1/4 Flange plug 76970 R1/8 Breather 76971 R3/8 Taper plug 78076 DIN 906-R1/4 Nozzle...
-
Page 15: Front Head
FRONT HEAD Item Description Part no. Specification Note Front head 78649 Upper tool bushing 78650 Tool retaining pin 78651 Ring 78652 Retaining pin 78653 Rubber plug 78654 (*) included in seal set Parts Manual MB/XP3025 15... -
Page 16: Lower Tool Bushing
LOWER TOOL BUSHING Item Description Part no. Specification Note Lower tool bushing (incl. part 2) 78655 Seal 78656 (*) included in seal set 16 Parts Manual MB/X3025... -
Page 17: Tool
TOOL Item Description Part no. Specification Note Chisel 78657 L=1120 mm, W= 112 kg D= 135mm Moil point 78658 L=1120 mm, W= 108 kg D= 135mm Blunt 78659 L=920 mm, W= 100 kg D= 135mm Long chisel 78660 L=1270 mm, W= 129 kg D= 135mm Long moil point 78661... -
Page 18: Seal Set
SEAL SET This summary only indicates the position of the seals. It must NOT be used as assembly instruction. Read the manual. 18 Parts Manual MB/X3025... - Page 19 SEAL SET Item Description Part no. Specification Note Seal set (inc. parts 1-22) 78667 Seal 76924 D114 O-ring 76844 Usit-ring 76846 8-13.9-1 O-ring 77789 D105 Seal 77790 D110 O-ring 76939 O-ring 76940 O-ring 76941 O-ring 78628 O-ring 78066 Seal 78067 Seal 78068 O-ring...
-
Page 20: Service Kit
SERVICE KIT Item Description Part no. Specification Note Service kit (incl. parts 1-4) 78668 Membrane 77779 Tool retaining pin 78651 Lower tool bushing 78655 Seal set 78667 20 Parts Manual MB/X3025... -
Page 21: Service Kit 2A
SERVICE KIT 2A Item Description Part no. Specification Note Service kit (incl. parts 1-4) 78669 Buffer 78603 77770 Wear plate 78611 Upper tool bushing 78650 Parts Manual MB/XP3025 21... -
Page 22: Manual Greasing
MANUAL GREASING Item Description Part no. Specification Note Hose assembly (incl. parts 2-9) 77706 Sleeve 77707 Insert 77708 Hose 77709 L=480 77710 Connector 77711 BSPP 3/8 Connector 77712 BSPP 1/4 Adapter 77713 Grease zerk 77714 Pipe clamp 77715 Plug 77716 Plug 77717 22 Parts Manual MB/X3025... -
Page 23: Greasing Device Kit
GREASING DEVICE KIT Parts Manual MB/XP3025 23... - Page 24 GREASING DEVICE KIT Item Description Part no. Specification Note Greasing device RG541 77719 Hose assembly (incl. parts 3-6) 77720 Sleeve 77707 Insert 77708 Hose 77721 77710 Rubber bushing 77722 Shield 77723 Hex. screw 77724 M10x110-8.8 ISO 4014 Lock washer 77725 M10 NL 10sp NORD-LOCK Grease cartridge 77726...
-
Page 25: Greasing Device
GREASING DEVICE Parts Manual MB/XP3025 25... - Page 26 GREASING DEVICE Item Description Part no. Specification Note Greasing device RG541 (incl. parts 2-16) 77719 Doser (incl. parts 3-16) 77730 Plug 77731 77732 M12x1 DIN 934 Lock washer 76854 M24 NORD-LOCK O-ring 77733 Adjusting screw 77734 O-ring 77735 O-ring 77736 Spring 77737 Piston...
