Stanley MB/XP2015
HYDRAULIC BREAKER
Parts Manual
Part Number PMMB/XP2015XENG.B17

Advertisement

Table of Contents
loading

Related Manuals for Stanley XP2015

Summary of Contents for Stanley XP2015

  • Page 1 Stanley MB/XP2015 HYDRAULIC BREAKER Parts Manual Part Number PMMB/XP2015XENG.B17...

  • Page 2: Table Of Contents

    • Mode of delivery (air mail etc.) It is important that you use only genuine Stanley spare • Required delivery date parts, to ensure easy operation maintenance and re- •...
  • Page 3 PARTS Parts Manual MB/XP2015 3...

  • Page 4: Housing Unit

    HOUSING UNIT 4 Parts Manual MB/XP2015...
  • Page 5 Lock nut 76907 M24-12 DIN 985 Wear plate 76908 Shield plate 76909 Seal 76910 Rubber plug 76911 Lifting eye 76912 M24 DIN 580 Hex. screw 76913 M24x35-8.8 ISO 4017 Wear parts 76914 Safety label set 76832 Parts Manual MB/XP2015 5...

  • Page 6: Accumulator

    Accumulator screw 76920 M20x55-8.8 ISO 4762 Filling plug 76921 Usit-ring 76846 8-13.9-1 Shield plug 76922 Parallel pin 76923 10m6x30 ISO 8734 Seal 76924 D114 O-ring 76844 Accumulator screw 76925 M24x110-8.8 ISO 4762 (*) included in seal set 6 Parts Manual MB/XP2015...

  • Page 7: Main Valve

    Part no. Specification Note Cover 76926 Main valve bushing 76927 Main spool 76928 Spool 76929 Spool 76930 Seal 76931 O-ring 76932 Hex. screw 76933 M16x35-8.8 ISO 4017 Lock washer 76852 M16 NORD-LOCK (*) included in seal set Parts Manual MB/XP2015 7...

  • Page 8: Pressure Control Valve

    PRESSURE CONTROL VALVE 8 Parts Manual MB/XP2015...
  • Page 9 Shim plate 76951 S=0.5 Shim plate 76952 Shim plate 76953 S=0.75 Plug 76954 O-ring 76955 O-ring 76838 O-ring 76956 Seal 76957 Hex. screw 76958 M12x30-8.8 ISO 4017 Lock washer 76959 M12 NORD-LOCK (*) included in seal set Parts Manual MB/XP2015 9...

  • Page 10: Tie Rods

    TIE RODS Item Description Part no. Specification Note Tie rod set (incl. parts 2-6) 76960 Vibration dampening element 76961 Cable tie 76962 Rubber ring 76963 Lock plate 76964 Spacer 76965 10 Parts Manual MB/XP2015...

  • Page 11: Body Parts

    BODY PARTS Parts Manual MB/XP2015 11...
  • Page 12 Hex. screw 76976 M10x12 ISO 4026 Piston 76977 Parallel pin 76978 10x70 ISO 8734 Wiper 76979 Seal 76980 Seal 76981 Wiper 76982 Seal 76983 Seal 76984 O-ring 76985 O-ring 76986 D172 (*) included in seal set 12 Parts Manual MB/XP2015...

  • Page 13: Front Head

    FRONT HEAD Item Description Part no. Specification Note Front head (incl. part 2) 76987 Plug 76988 Upper tool bushing 76989 Tool retaining pin 76990 Ring 76991 Retaining pin 76992 Rubber plug 76993 Parts Manual MB/XP2015 13...

  • Page 14: Lower Tool Bushing

    LOWER TOOL BUSHING Item Description Part no. Specification Note Lower tool bushing (incl. part 2) 76994 Seal 76995 14 Parts Manual MB/XP2015...

  • Page 15: Tool

    TOOL Item Description Part no. Specification Note Chisel 76996 L=1000 mm, W=67kg D=115mm Moil point 76997 L=1000 mm, W=67kg D=115mm Blunt 76998 L=800 mm, W=58kg D=115 mm Pyramid 76999 L=1000 mm, W=66 kg D=115 mm Parts Manual MB/XP2015 15...

  • Page 16: Seal Set

    76981 Wiper 76982 Seal 76983 Seal 76984 O-ring 76985 O-ring 76986 D172 Seal 76942 The seals for greasing device are not included in this seal set. They are included in the service kit for greasing device. 16 Parts Manual MB/XP2015...

  • Page 17: Service Kit

    SERVICE KIT Item Description Part no. Specification Note Service kit (incl. parts 1-4) 77704 Membrane 76919 Tool retaining pin 76990 Lower tool bushing 76994 Seal set 77703 Parts Manual MB/XP2015 17...

  • Page 18: Service Kit 2

    SERVICE KIT 2 Item Description Part no. Specification Note Service kit (incl. parts 1-4) 77705 Buffer 76902 76903 Wear plate 76908 Upper tool bushing 76989 18 Parts Manual MB/XP2015...

  • Page 19: Manual Greasing

    Specification Note Hose assembly (incl. parts 2-9) 77706 Sleeve 77707 Insert 77708 Hose 77709 L=480 77710 Connector 77711 BSPP 3/8 Connector 77712 BSPP 1/4 Adapter 77713 Grease zerk 77714 Pipe clamp 77715 Plug 77716 Plug 77717 Parts Manual MB/XP2015 19...

  • Page 20: Greasing Device Kit

    GREASING DEVICE KIT 20 Parts Manual MB/XP2015...
  • Page 21 Greasing device cartridges are also sold in boxes of Shield 77727 Hex. socket screw 77728 M16x35-8.8 ISO 4762 Lock washer 76852 M16 NORD-LOCK Connector 77711 BSPP 3/8 Connector 77712 BSPP 1/4 Hose assembly 77729 Parts Manual MB/XP2015 21...

  • Page 22: Greasing Device

    GREASING DEVICE 22 Parts Manual MB/XP2015...
  • Page 23 Spring housing 77755 Spring 77756 Piston 77757 77758 Lock plate 77759 Hex. socket screw 77760 M8x10-8.8 ISO 4762 Connector 77712 BSPP 1/4 Seal set for greasing device 77761 (*) included in seal set for greasing device Parts Manual MB/XP2015 23...
