Kwikset SmartCode 914 Installation And User Manual page 2

4 Install the exterior keypad
A
What is the diameter of the hole in the door?
Diameter is 2 1/8"
(54 mm)
or
2 1/8"
54 mm
"D" is required for installation. "D" is not needed for
Install "D" on "F". installation. Discard "D".
F
D
B
Locate the screws for step 4C and keep them within reach.
T
5 Install the interior assembly
A
Remove the interior cover and battery pack from the interior assembly.
a
Make sure the turnpiece is
in the vertical position.
c
Make sure
turnpiece shaft is
rotated as shown.
L
6
Install the batteries and perform the door handing process
This step will teach your lock the orientation of your door and is crucial to lock operation.
A
Install 4 AA batteries in the battery pack.
W
K
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
C
Install the exterior keypad and mounting plate.
Diameter is 1 1/2" a
(38 mm)
1 1/2"
38 mm
D
c
screws evenly.
B
b
L
M
d
K
Do not install
batteries
until step 6.
L
B
With the door open, press and HOLD the
Lock button while installing the battery pack.
Hold the button until the latch bolt
starts moving on its own.
K
2 / 4
actual
size
b
F
The cable goes
underneath the latch.
d
Keep parallel to the
edge of the door.
T
T (2x)
Tighten
Install the interior assembly onto the mounting plate.
a
L
align
Ensure tight cable
connection.
c
C
The latch will retract and extend to learn the orientation of the door.
If the bolt does not move,
make sure the batteries
are correctly installed, and
perform step 6B again.
D
The Status LED will indicate success or failure.
T
Support the exterior
assembly during mounting
plate installation.
G
Route the cable
through the center
hole, then push it into
the bottom hole.
E
Insert the key and
test the latch. If the
latch does not extend
or retract smoothly,
adjust the screws (T).
Remove the key when
inished, and make
sure the latch bolt
is fully extended.
actual
size
U
b
Lay the excess cable
lat inside the bottom of
the interior housing.
d
U
(2x)
bottom
hole
Note: The latch
bolt will only
retract half way.
Green: Door handing was
successful. Proceed to next step.
Red: Door handing was
unsuccessful. Make sure the lock
interior and batteries are correctly
installed. Perform step 6B again.
