i u
nstructions for se
The lights will stay On even when you stop. Once activated, the
text "light On" appears on the screen. Even when the battery
gauge shows 'empty', there is enough energy to run the lights for
about two hours. If the battery pack is fully drained, the lights will
be powered by the system as it switches to generative mode
automatically. To switch the lights Off, hold the , button for
2 seconds. After switching Off, the text "light Off" will appear on the screen.
• Mountain mode
The "Mountain Mode" allows for longer uphill riding before the motor shows power reduction due to
so-called "temperature-derating". As "Mountain Mode" limits the maximum motor torque the motor
will stay cooler for a longer period of time. Select this option by going to assistance level 4 and then
press-and-hold the '+' button for 2 seconds. To return to assistance level 4, press the '-' button once.
• Changing the language option of the controller
The RIDE+ Pro controller allows you to change the language that is displayed on the screen.
See the part 'Programming' later in this manual to set the correct language.

3.2 Removing and installing the RIDE+ Pro controller

To remove the RIDE+ Pro controller from the bike, press the catch of
the holder and slide the controller off towards the rear. To install the
RIDE+ Pro controller onto the handlebar, align the controller with its
clamp and slide the controller forward until it clicks.
NOTICE. To prevent loss of riding information, please make sure that the controller is switched Off
before it is removed from the bike.
• Unintended removal of controller out of its dock
If the controller is moved off its clamp while the system is active ('On'), the system will no longer
assist, even when the controller is replaced into its clamp. Please select the correct level of
assistance again to reactivate the system.

3.3 Programming the RIDE+ Pro Controller

This section explains how you set the odometer units (miles or
kilometers), the clock, the wheel diameter and how you can swap
the functionality of the buttons and select the correct language. To
enter programming mode, press buttons 'On/Off' and 'Mode-
switch' for two seconds. Four zeros will appear, with the first zero
blinking. Enter the appropriate code by pressing button '+' for a higher value, '-' for a lower value.
Press button 'On/Off' to select a value and move to the next digit. After entering the correct value
for the fourth digit, press button 'On/Off' to move into the chosen menu. In the programming
menu, buttons '+' and '-' will move to a higher or lower value. Pressing button 'On/Off' will save the
entry and move you to the next step, or back to the regular display.
'2001' '2004' '2009'
Codes: to switch between miles and kilometers; to set the time; to
'2011'
swap the function of the buttons from left to right and vice versa; to change the display
'3771'
language. Use button to scroll through the languages; to set the correct wheel diameter.
EN-12
