TECshow NAVIGATOR NODE 8 User Manual page 5

1/2/3/4/5/6/7/8
Eight DMX port
NAVIGATOR NODE
ENGLISH VERSION
The second line:
√/x
A/B
The third line: ―
The second line:
√/x/ ―
The third line:
√: network cable connected
X: network cable NOT connected
Flash between √and x under the DHCP
mode: means the fixture is still searching for
IP address. Or means no IP address.
― Means both port DHCP enable, otherwise
both port static IP
√: DMX signal available
X: NO DMX signal
― means disable status
― Means DMX input status, otherwise
means output status (when second line is,
the third line must be, it means the
disable status)
p. 5
