- Page 1 C255 / C257 Long Life Industrial EOS Analyzer INSTRUCTION MANUAL ENGLISH O2% 9.7 1.47 TFf 87.4 Down Enter Flue Test Fuel Exch Test Status Temp Room Menu C225 CO ∆T PRS I N D U S T R I A L E O S A N A L Y Z E R 1.800.561.8187...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Display Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Where To Test . -
Page 3: Analyzer Overview
ANALYZER OVERVIEW Worklight Infrared Printer Port O2% 9.7 4 Line Backlit Display 1.47 BACKLIGHT / “s“ UP: Press to turn TFf 87.4 Backlight/Worklight on/off . Press and hold to select between Flue Test page 1 and page 2 and navigate “UP” Down Enter On/Off Button... -
Page 4: Getting Started
GETTING STARTED SAFETY NOTES Before using this meter, read all safety information carefully . “WARNING” is used to indicate conditions or actions that may pose physical hazards to the user . “CAUTION” is used to indicate conditions or actions that may damage this instrument . WARNING! This analyzer extracts combustion gases that may be toxic in relatively low concentrations . -
Page 5: Set Language
-------- MENU MENU / SETUP (CONT.) SETUP SET TEMPERATURE SCALE -------- -------- -------- -------- Down Enter MENU SETUP C<---->F Flue Test SETUP Fuel C<---->F Exch Test Temp Status -------- -------- -------- Room Menu Down Enter Down Enter Down Enter Flue Test Flue Test Flue Test Fuel... - Page 6 MENU / SETUP (CONT.) SETUP SET OUTPUT -------- Note: If incorrectly set you -------- -------- -------- will have an incomplete Down Enter printout on the UEi KMIRP2 MENU SETUP OUTPUT (KMIRP) . Flue Test Fuel SETUP OUTPUT KMIRP Exch Test...
- Page 7 -------- MENU MENU / PRESSURE (CONT.) SETUP RESOLVE (RESOLUTION) -------- Note: High resolution -------- -------- -------- provides 0 .001” H2O Down Enter MENU PRESSURE RESOLVE resolution and is useful when performing static Flue Test PRESSURE RESOLVE Fuel Exch Test pressure tests . -------- -------- --------...
- Page 8 -------- MENU MENU / SCREEN SETUP CONTRAST -------- -------- -------- -------- Down Enter MENU MENU CONTRAST SCREEN CONTRAST Flue Test Fuel Exch Test -------- -------- -------- Status Temp Room Menu Down Enter Down Enter Down Enter Flue Test Flue Test Flue Test Fuel Fuel...
-
Page 9: Basic Fast Start (Operation)
-------- Nat Gas UP DOWN MENU BASIC FAST START (OPERATION) SET TIME 1. POWER ON 2. SELECT FUEL CHANGE -------- FRESH Down Enter Nat Gas Down Enter UP DOWN Flue Test Fuel Flue Test Exch Fuel PURGE Test Exch Test Temp Status Status... - Page 10 Fuel Rotate dial to Fuel . Press “s“ UP or “t“ DOWN Nat Gas Nat Gas to scroll to select desired Analyzer will display the fuel . Top line displays current fuel being used for UP DOWN UP DOWN selected fuel for calculations . calculations .
- Page 11 P1 and Status Temp Room Room Menu Menu P2 to measure differential pressure . UEi recommends the ASP1 static probe C225 C225 tips to measure static CO ∆T PRS CO ∆T PRS Press “Send” to print results or press...
-
Page 12: Temp
Temp This test is useful for quick checks of temperature rise, and differential/delta T along with other HVAC temperature applications . Rotate dial to Temp Observe T1, T2 and TEMP TEMP Differential/delta T . Connect flue probe T1f 000 T1f 000 thermocouple or accessory Press “Send”... -
Page 13: Fuel
Manomode allows you to see dual temperature and pressure readings without having to allow the analyzer to purge for combustion testing . To access Manomode press Analyzer will enter and hold “Send” while “MANOMODE” after a 4 MANOMODE UEi C255 turning the analyzer on . second countdown and automatically zero the “MANOMODE” will appear 09:55:31 pressure sensor . -
Page 14: Where To Test
WHERE TO TEST Air Conditioning / Heat Pump Suction Line: • Temperature Verify proper: • Static Duct Pressures • Temperature Differential • Static Pressure Drop Across Coils to condensing unit Boiler & Water Heaters & High Efficiency Modulating Hot Water Systems Boiler HE Boiler Instant Water Heater... -
Page 15: What Results Are Generally Acceptable
WHERE TO TEST (CONT.) Furnaces (continued): Atmospheric, Gas & Oil Natural Gas & Propane Verify proper combustion: • O2 • CO Atmospheric Furnace • Stack Temp Draft • Vent Pressure • Efficiency Verify proper • Temperature Rise Test • AC side Static Pressure •... -
Page 16: General Maintenance
GENERAL MAINTENANCE • Re-certify your instrument annually to ensure it meets original performance specifications • Keep your instrument dry . If it gets wet, wipe dry immediately . Liquids can degrade electronic circuits • Whenever practical, keep the instrument away from dust and dirt that can cause premature wear •... -
Page 17: Replacing Batteries
REPLACING THE BATTERIES This meter has been designed for use with both alkaline and rechargeable Nickel Metal Hydride (NiMH) batteries . No other types are recommended . The analyzer is supplied with 4 “AA” size alkaline batteries . These should be installed into the instrument as shown in the diagram indicated on the back of the unit . -
Page 18: Other Important Factors Related To Combustion
. As an example you would measure the CO2 level and the stack tempera- ture and then reference a slide scale that would give you the relative efficiency number . UEi’s electronic combustion analyzers perform the measurements on a continuous basis, and can calculate the efficiency as adjustments are being made . -
Page 19: Specifications
• If not, adjust the position of the instrument to minimize interference or switch off, if possible, the offending equipment for the duration of the test At the time of writing this manual (April 2015) UEi is not aware of any field based situation where such interference has ever occurred and this advice is only given to satisfy the requirements of the Directive .
