Dynojet Power Commander V Installation Instructions page 3

FIG.A
FIG.B
FIG.C
25-007 www.powercommander.com
1 Remove the center console, glove compartment, ignition switch board, and
both passenger side engine compartment cover panels.
2 The motor compartment will be exposed as shown in Figure A.
3 Using the supplied velcro, secure the PCV to the driver side engine cover as
shown in Figure B.
Make sure to clean both surfaces with the alcohol swab before attaching.
4 Attach the ground wire from the PCV to the negative side of the battery as
shown in Figure B.
5 Route the PCV harness over the engine cover and route the harness along the
intake plenum as shown in Figure C.
11-12 Can-Am Commander 800 PCV - 3
