Stereoping synth programmer Owner's Handbook Manual
For waldorf microwave
Hide thumbs
Also See for synth programmer:
- Owner's handbook manual (16 pages) ,
- Operation manual (20 pages) ,
- Owner's handbook manual (24 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Operating Manual
Advertisement
Table of Contents
Related Manuals for Stereoping synth programmer
Summary of Contents for Stereoping synth programmer
- Page 2 ___________________________________________________________________________________________________________2 Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018...
-
Page 3: Table Of Contents
Randomizer Modes and their effect............................17 10.CHORD MEMORY............................18 Triggernotes....................................18 Chord Setup....................................18 Learning modes 'Toggle' and 'Hold'............................18 11.CC to SysEx translator........................... 19 12.Updating Firmware............................20 13.Imprint................................21 Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 4: General Features Of The Synth Programmer
Technical handling The Synth Programmer was built to be used in a comfortable music studio environement. You can operate it under free skies of course. But please keep in mind, it uses electricity for proper operation and therefore is quite sensitive to water, drinks or other fluids. -
Page 5: Connections And Integration Into Your Setup
You can use any ordinary 9 Volt DC powersupply to operate your controller. The connector should have Plus on it's center pin and Ground - sometime labeled as 'Minus' - on the outside. The Synth Programmer has a protection diode for not doing any harm if the polarity of the power supply is wrong, it just won't work. The current of the PSU should at least offer about 200 mA (=0.2 A). -
Page 6: Settings And Workflow
Settings and workflow____________________________________________________________________________________6 2. Settings and workflow Settings on the Microwave MIDI Param - Midi Chan. - sould be set to the same midichannel as the Synth Programmer • Midi Param - Prog Change → 'on' • Midi Param - PC Maps → 'off' •... -
Page 7: Overview
Press MULTI again to leave this mode. Any details about the Mutli mode in Chapter 6. Multi Mode Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 8: Button 'Peek
This leads to the PATCH-Mode, the place to select patches on your Microwave. As soon as you select a program here, the Synth Programmer will cause the Microwave to call this program and send the parameter values to the Programmer for both to be in sync. More on this in Chapter 7. Patch Mode By holding PATCH for 2 seconds you enter the Programmers Randomizer. -
Page 9: Play Mode
• WAVE2 (Wavetable, Env Velocity, Keytrack, Wave Mode) • GLIDE (Mode, Type, Temperment, Patch Name) • LFO1 (Humanize, Sync, Delay, Attack, Decay) • Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 10: Wavetable Selection
Being on the PROGRAM NAME page play some notes on your keyboard, each key selects another letter/number/sign. Heavy press: CAPITAL LETTER; mellow keypress: normal letter. One more: you can use the Modulation Wheel to shift the cursor :-) Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 11: Modulation Mode
The Microwave has got quite powerful modulation possibilities. The modulation slots are not organized in one place. The engineers have spread them all over the parameter pool, near the parameter they should modulate. The Stereoping Programmer wants to simplify the access to this modulation zoo. As mentioned above you enter this mode by pressing MOD. -
Page 12: Multi Edit Mode
For finetuning a layersound maybe: row 1: Volume • row 2: Velo Limit H • row 3: Velo Limit L • row 4: Output Select • Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 13: Setup Left / Right And The 3Rd Setup Turn Dial
Program's parameters without always having to save after each change on a program. Your Synth Programmer can only hold ONE Program in memory for displaying original values. But nothing holds it back from sending Parameter edits to each of the first 6 Multi-Instruments. This is exactly what you will allow on setting the PREFS Parameter MultInstSwap to ON: being in MULTI Mode each of the 6 pot columns (no matter if left or right) silently sets the target instrument where all the parameter tweaks in PLAY Mode will be sent to. -
Page 14: Patch Mode
MULTI Mode the Programmer can only display original values for the Multi Instrument which was currently active while requesting the Single Program. Which is 1 after powerup (or if the PREFS parameter MultInstSwap is set to OFF). Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 15: Prefs Und Midi Bypass Mode
Programmer would not be in between at all. This mode is quite useful if you want to dump some soundbanks into the Microwave. You can leave MIDI BYPASS MODE at any time pressing PREFS again. Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 16: Randomizer
Randomizer. Your random patch replaces it and is now the currently editied Program in PLAY Mode. Press 'BACK' and you find yourself in Randomizer again. Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 17: Randomizer Modes And Their Effect
Tip: if the Randomizer has set Cutoff to 002 again and you wont hear anything … all turn dials are fully functional in randomizer :-) Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 18: Chord Memory
SAVE – all changes in the chord slots will be saved • BACK – leads back into the Chord Setup • XIT – Chord Setup will be left without making any changes • Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 19: Cc To Sysex Translator
-64 to +63. TO archive a value of 0 you have ti send the CC value of 64. Due to technical reasons the Programmer does not show permanent value changes when translating CC into SysEx data. Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018... -
Page 20: Updating Firmware
12. Updating Firmware The day may come you want to update your edition or try out another. Your Synth Programmer offers a firmware update mode for this. After entering this mode you just send a firmware-file into the controllers Midi IN 2 jack. -
Page 21: Imprint
Stereoping is a registered trademark of Gregor Zoll, Germany. Adresse Gregor Zoll Musikelektronik Hermann-Voss-Str. 21 59872 Meschede Germany E-Mail h e llo@stereoping. com Homepage http://www.stereoping.com Synth Programmer for Waldorf Microwave – Operation manual V 1.0 – 01/2018 © Stereoping Germany, Meschede 2018...
