Stereoping Synth Programmer Owner's Handbook Manual

For oberheim matrix 6/6r/1000
Hide thumbs Also See for Synth Programmer:
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Synth Programmer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stereoping Synth Programmer

Summary of Contents for Stereoping Synth Programmer

  • Page 2: Table Of Contents

    9.PREFS und MIDI BYPASS MODE........................17 10.CHORD MEMORY............................18 11.CC to SysEx translator........................... 19 12.Updating Firmware............................20 13.Matrix 1000 hints............................21 14.Init Patch................................ 22 15.Imprint................................23 Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...
  • Page 3 Technical handling The Synth Programmer was built to be used in a comfortable music studio environement. You can operate it under free skies of course. But please keep in mind, it uses electricity for proper operation and therefore is quite sensitive to water, drinks or other fluids.

  • Page 4: Connections And Integration Into Your Setup

    You can use any ordinary 9 Volt DC powersupply to operate your controller. The connector should have Plus on it's center pin and Ground - sometime labeled as 'Minus' - on the outside. The Synth Programmer has a protection diode for not doing any harm if the polarity of the power supply is wrong, it just won't work. The current of the PSU should at least offer about 200 mA (=0.2 A).

  • Page 5: Info & Settings Matrix 6 / 6R

    – please work on a copy of it on another patch number. Restrictions for using the Synth Programmer together with the Matrix 6 OS V2.13 For any changes of the modulation matrix and the negative values of bipolar parameters the whole patch will be dumped into the Matrix.
  • Page 6 The Matrix 6 only reacts to incoming Midi SysEx Parameter commands when being in QUICK EDIT mode. The Synth Programmer sends a little command to let the Matrix jump into this mode on each parameter change. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020...

  • Page 7: Info & Settings Matrix 1000

    Matrix to do so. In case you gorgot the saving procedure: hold 'ENTER' and press a number between 000 and 199. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...
  • Page 8 Programmer individually between both connected Matrix. This also works with two Matrix 6 or 1000 and 6 mixed. For more details and the full featurelist please check out the product's page on our website. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...
  • Page 9 Programmer and both will change their parameters. If the 2nd unit is a Matrix6 you need to set it to QUICK EDIT mode manually after each patch change or it will not respond to parameter changes. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 10: Overview

    M1000 by heart this might be your weapon. Press RAND again to get back to PLAY Mode. The Randomizer will be handles in detail in Chapter 7. Randomizer. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...
  • Page 11 This leads to the PATCH-Mode, the place to select patches on your Matrix. As soon as you select a program here, the Synth Programmer will cause the Matrix to call this program and request the related parameter values into the Programmer for both to be in sync. More on this in Chapter 8. Patch Mode Synth Programmer for Oberheim Matrix - Operation manual V 1.6 –...

  • Page 12: Play Mode

    OS versions this dial sends Pressure. Pressure perfectly can be used as source in the Modmatrix and will is made use of in many presets. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...
  • Page 13 There is no need switching it off, simply switch Chord Memory on and off again. Entering CHORD MEMO sends an 'All Notes Off' command, the Matrix should be quiet again then. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 14: Matrix Mode

    MATRIX Mode___________________________________________________________________________________________14 6. MATRIX Mode The Stereoping Programmer allows full and comfortable access to the modulation matrix. After pressing the MOD button, it's LED should light up and the display should show the following information: in the upper left you see the Modulation source, •...

  • Page 15: Randomizer

    Note: all the dials are still active in randomizer of course. If you wont hear any sound after creating a random patch it might be worthy tuning CUTOFF or VOL ENV AMOUNT before pressing DO again :-) Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 16: Patch Mode

    Miditool called PolyChainer for stacking two Matrix 6 or 1000. After the dump both connected synthesizers hold the same program to sound identical. Or use 'XIT' to leave Patch Mode. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 17: Prefs Und Midi Bypass Mode

    Programmer would not be in between at all. This mode is quite useful if you want to dump some soundbanks into the Matrix. You can leave MIDI BYPASS MODE at any time pressing PREFS again. Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 18: Chord Memory

    SAVE – all changes in the chord slots will be saved • BACK – leads back into the Chord Setup • XIT – Chord Setup will be left without making any changes • Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 19: Cc To Sysex Translator

    Env3 Velocity Lfo1 Speed Lfo1 Wave Lfo1 Amp Lfo2 Speed Lfo2 Wave Lfo2 Amp Ramp 1 Rate Ramp 2 Rate VCA 1 Vol Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 20: Updating Firmware

    12. Updating Firmware The day may come you want to update your edition or try out another. Your Synth Programmer offers a firmware update mode for this. After entering this mode you just send a firmware-file into the controllers MIDI IN 2 jack.

  • Page 21: Matrix 1000 Hints

    ◦ press SELECT until 'Ext. Func.' LED lights up ◦ press '7', then ENTER. The display shows '0'. Press ENTER again ◦ The display shows 'Cal' for 10-30 secunds Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 22: Init Patch

    VCF F<ENV1 VCF F<Pressure VCA1<Velo VCA2<ENV2 Env1&3 Amp<Velo Env2 Amp<Velo LFO1/2 Amp<Ramp1/2 Porta rate<Velo VCF FM<ENV3 VCF FM<Pressure LFO1/2 Speed<Pressure/Keyboard Modulation Matrix All 0 Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...

  • Page 23: Imprint

    Stereoping is a registered trademark of Gregor Zoll, Germany. Adresse Gregor Zoll Musikelektronik Hermann-Voss-Str. 21 59872 Meschede Germany E-Mail h e llo@stereoping. com Homepage http://www.stereoping.com Synth Programmer for Oberheim Matrix - Operation manual V 1.6 – 05/2020 © Stereoping Germany, Meschede 2020...
