Summary of Contents for GreenWorks 2600400
- Page 1 12" 40V Cordless Snow Shovel 2600400 To order: Battery (Sold Separately) (4Ah Model # 29662) Charger (Sold Separately) (Model # 29692) Owner’s Manual TOLL-FREE HELPLINE: 1-888-909-6757 Read all safety rules and instructions carefully before operating this tool. www.greenworkstools.com...
-
Page 2: Table Of Contents
CONTENTS Contents ..........................2 ......................2 Safety information ......................3-5 Symbols ..........................6-7 Know your snow shovel ....................... 8 Assembly ........................9-10 Operation ........................11-14 Environmentally safe battery disposal..................15 Maintenance ......................... 16-20 Troubleshooting ......................... 21 Warranty ..........................22 Exploded View ........................23 Parts List.......................... - Page 3 SAFETY INFORMATION FOLLOW THESE RULES WHILE OPERATING THE SNOW SHOVEL I M P O R T A N T READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below • Walk. Do not run. • Verify that the snow shovel is not in contact with anything before turning it on. •...
-
Page 4: Safety Information
SAfETY infORMATiOn • Do not attempt to clear the impeller while the motor is running. • Keep clothing and body parts away from the impeller. • Stop the motor when stopped or when moving from one location to another. • Remove the battery pack when it is being transported and when it is not in use. •... - Page 5 USE OnLY GREEnWORKS APPROVED REPLACEMEnT BATTERiES, OTHER BATTERiES MAY CAUSE inJURY OR DAMAGE TO THE SnOW SHOVEL. USE OnLY WiTH GREEnWORKS 40V BATTERiES (Model#: 29662) and GREEnWORKS 40V CHARGER (Model#: 29692). w A R N I N G ( P R O P O s I T I O N 6 5 )
-
Page 6: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. sYMBOL dEsIGNATION/EXPLANATION Voltage Current frequency (cycles per second) Watt Hour - Energy Storage Capacity Amp Hour - Current Capacity Direct current... -
Page 7: Symbols
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. sYMBOL sIGNAL MEANING dANGER indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. wARNING indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury. -
Page 8: Know Your Snow Shovel
KNOW YOUR SNOW SHOVEL Read this operator's manual and safety rules before operating your snow shovel. Compare the illustration in Figure 1 to your snow shovel in order to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. Battery Battery compartment Auxiliary handle... -
Page 9: Assembly
ASSEMBLY inSTRUCTiOnS UNPAcKING • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • inspect the product carefully to make sure no breakage or damage occurred during shipping. •... - Page 10 ASSEMBLY inSTRUCTiOnS cONNEcTING THE sHAFTs (See Figure 2-3) • Align the pin on the handle shaft and the hole on the lower shaft. (fig. 2). • Turn the lock knob clockwise until it is fully tightened. (fig. 3). Handle shaft Lock knob Lower shaft Hole...
-
Page 11: Operation
OPERATING INSTRUCTIONS TO INSTALL BATTERY PACK (NOT INCLUDED) (See Figure 4) • Slide the battery (1) down to lock it into position. The battery is fully inserted into the snow shovel when you hear an audible “click”. Fig. 4 TO REMOVE BATTERY PACK (See Figure 4) •... - Page 12 CONTENTS OPERATinG inSTRUCTiOnS AdJUsT THE AUXILIARY HANdLE HEIGHT (See Figures 5) • Loosen the bolts until the auxiliary handle is no longer secured. • Move the auxiliary handle to the height you prefer, make sure the raised points on the auxiliary handle are aligned with the groove on one side of the handle shaft.
- Page 13 CONTENTS OPERATinG inSTRUCTiOnS sTARTING THE sNOw sHOVEL (See Figures 6-7) in order to avoid serious injury, the operator and unit must be in a stable position when starting the snow shovel. follow this sequence exactly in order to start the snow shovel. •...
- Page 14 OPERATinG inSTRUCTiOnS UsING THE sNOw sHOVEL (See Figures 8) • Start the snow shovel by following the Starting instructions. The depth and weight of the snow will determine the forward speed. • Push the snow shovel forward so that it rides on the scraper. scraper Fig.
-
Page 15: Environmentally Safe Battery Disposal
EnViROnMEnTALLY SAfE BATTERY DiSPOSAL The following toxic and corrosive materials are in the batteries used in this tool battery pack: Li-ion, a toxic material. w A R N I N G All toxic materials must be disposed of in a specified manner to prevent contamination of the environment. - Page 16 MAinTEnAnCE sERVIcING Servicing should be performed by a qualified technician. Replacement parts for this snow shovel must be identical to the parts that they replace. if repairs are necessary, contact the Toll-free Helpline, at 1-888-908-6757. REPLAcING THE scRAPER (See Figure 9-10) w A R N I N G IN ORdER TO AVOId sERIOUs PERsONAL INJURY, TURN THE sNOw sHOVEL OFF ANd REMOVE BATTERY BEFORE PERFORMING ANY MAINTENANcE.
- Page 17 MAinTEnAnCE sTORAGE • Allow the motor to cool down before storing. • Store the snow shovel in a locked location in order to prevent unauthorized use or damage. • Store the snow shovel in a dry, well-ventilated area. • Store the snow shovel out of the reach of children. cLEANING in order to avoid serious personal injury, turn the snow shovel off and remove battery before cleaning or servicing.
- Page 18 MAinTEnAnCE TRANsPORTING THE sNOw sHOVEL (See Figure 11) • Allow the motor to cool down before transporting. • Secure the snow shovel while transporting. • When moving the snow shovel, grasp it by the top handle and auxiliary handle. (fig. 11). Fig.
-
Page 19: Maintenance
MAINTENANCE IMPELLOR REPLACEMENT screw Washer • Remove the right side • Pull the belt tensioner (idler • Remove the belt. cover by removing 6 arm) away from the drive screws. pulley. Be sure not to lose the washer and screw left. •... - Page 20 MAINTENANCE IMPELLOR REPLACEMENT • Replace and tighten the • Replace and tighten the • Replace and tighten the remaining nut to secure the remaining screws to secure remaining screws to secure left side plate assembly. the left side cover. the pulley assembly. •...
-
Page 21: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION The battery is not charged. Charge the battery by following the procedures in the battery and charger manual. The lock-out button or trigger Press and hold the lock-out button, switch were not used properly. while holding lock-out button, press the switch trigger. -
Page 22: Warranty
(4) years against defects in materials, parts or workmanship. GREENWORKS™, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer. This warranty is valid only for... -
Page 23: Exploded View
EXPLODED ViEW... -
Page 24: Parts List
PARTS LIST ITEM NO. PART NO. DESCRIPTION 311101478 Snow thrower main body 311041469A Motor assy 311121468 Belt tensioner assy 329011468 Belt 311131468 Impeller shaft assy 3220401 Screw 3390198 Spring 32205877 Screw 341041468 Scraper 341031468 Impeller 362011471 PCB board 32201836 Bolt & Washer assy 311031468 Auxiliary handle assy... - Page 25 TOLL-FREE HELPLINE: 1-888-909-6757(1-888-90WORKS) Rev: 01 (27-07-16) Printed in China...
