Page 1: User Manual
DS-4308MDI-E Audio/Video Decoding Card User Manual Version 6.5 2013-01-26 Model DS-4308MDI-E... - Page 2 It may not be reproduced in whole or in part, in any form, or by any means or be used for any other purpose without prior written consent of HIKVISION and then only on the condition that this notice is included in any such reproduction. No...
-
Page 3: Table Of Contents
Power Supply ................... 8 Chapter 4 Driver Installation ..................10 Chapter 5 Cable Connection and Pin Definition ............12 5.1. DS-4304MDI-E Accessories and Connection.......... 12 5.2. DS-4304MDI-E Video/Audio Output Pin Definition ........14 © 2013 by HIKVISION. All rights reserved. -
Page 4: Chapter 1 Product Description
Chapter 1 Product Description 1.1. Product Description HIKVISION DS-4308MDI-E decoding card supports up to WD1 video decoding, and outputs decoded video/audio data through BNC interfaces. The card can be plugged onto a PC motherboard and construct a PC-based decoding system together with management software, and meets different requirements of surveillance applications consequently. -
Page 5: Technical Specification
OggVorbis, G-711, MPEG1 Layer 2 Audio Input Audio Decoding 4-ch PCM audio, mono Capability Audio Output BNC (Linear level, 600 Ω) Interface PCI Standard PCI-Ex1 2.0 Dimensions 213 × 102 (mm) Power < 13.5 w Consumption © 2013 by HIKVISION. All rights reserved. -
Page 6: Product Features
8 video/audio output channel, up to 16 screen-split display for each video output Multiple input video standards (MPEG-4, H.264 , MJPEG, HIK H.264) Multiple input video packet type (ES, PS RTP and HIK) Multiple input audio standards (OggVorbis, G-711, MPEG1 Layer 2) © 2013 by HIKVISION. All rights reserved. -
Page 7: Developing Support
Support mix-use with other HIKVISION card models in 1 PC Up to 5 DS-4308MDI-E cards can be installed in 1 PC Provide driver, SDK and open-source demo for secondary developing © 2013 by HIKVISION. All rights reserved. -
Page 8: Chapter 2 Product Performance
Please kindly refer to http://www.hikvision.com or contact HIKVISION technical support for the latest updates of card performance. Performance may be slightly different according to the card number and PC HD read/write efficiency. © 2013 by HIKVISION. All rights reserved. -
Page 9: Chapter 3 Compatible Software/Hardware Configuration
Hardware Configuration 3.1. Operating System The DS-4308MDI-E card works in Windows7/ 2008/ Vista/ 2003/ XP Operating System installed with DirectX version 8.1 or higher version, or Linux Operating System. For Windows 2003 OS, please kindly follow the operation steps below. - Page 10 Hikvision Technical Manual Enable “DirectDraw” and “Direct3D” options in the “Display” column. © 2013 by HIKVISION. All rights reserved.
-
Page 11: Cpu And Motherboard
ASUS P8P67 LE ECS H67H2-M ASUS P8H61 PLUS Etc. Note: Please refer to HIKVISION website (http://www.hikvision.com) for up-to-date hardware compatibility information under ‘Support > FAQ’ 3.3. System Memory ≥1G Note: Larger memory size is required when the card number installed in the PC increases. - Page 12 Hikvision Technical Manual © 2013 by HIKVISION. All rights reserved.
-
Page 13: Chapter 4 Driver Installation
Click “Install or Update Driver” to install/update the driver, and a Windows dialog box will be displayed on screen. Click “Continue Anyway” to continue the hardware installation. © 2013 by HIKVISION. All rights reserved. - Page 14 After “Driver install success” message popup during driver installation, there will be “Hikvision DS43xx Series” displayed in the list “Sound, Video and Game Controller” of Windows Device Manager as below. The total number of this item is equal to the total DSP number on the cards installed inside the PC.
-
Page 15: Chapter 5 Cable Connection And Pin Definition
5.1. DS-4304MDI-E Accessories and Connection DS-4308MDI-E Connection DB3 DB4 4ch video + 4ch audio connection cable (2 units for each card) Description: VID1~VID4 stand for “video 1~video 4” when connected to DB1, and “video 5~video 8” © 2013 by HIKVISION. All rights reserved. - Page 16 DB2; AID1~AID4 stand for “audio 1~audio 4” when connected to DB1, and “audio 5~audio 8” when connected to DB2. DB1 video 1~video 4; audio 1~audio 4 DB2 video 5~video 8; audio 5~audio 8 © 2013 by HIKVISION. All rights reserved.
-
Page 17: Ds-4304Mdi-E Video/Audio Output Pin Definition
Hikvision Technical Manual 5.2. DS-4304MDI-E Video/Audio Output Pin Definition Each DS-4308MDI-E card has 2 DB 15-pin female connectors (labeled DB1 and DB2), and each DB15 connector supports 4ch video output and 4ch audio output. Pin Definition for DB1& DB2 Video1... - Page 18 Hikvision Technical Manual Pin Definition for DB3& DB4 Video1 Video5 Video2 Video6 Video3 Video7 Video4 Video8 Audio1 Audio5 Audio2 Audio6 Audio3 Audio7 Audio4 Audio8 © 2013 by HIKVISION. All rights reserved.
