QUICK START USER GUIDE
FIGURE 1 – INDUSTRIAL HIGHTHROUGHPUT WIRELESS ETHERNET LINK
PORT 1 - POE IN PORT 2 - POE OUT
FRONT
BOTTOM
FIGURE 2 – STATUS INDICATING LEDS

SIGNAL STRENGTH:

WEAK SIGNAL

TECH SUPPORT: 1.888.678.9427
PORT 2 - POE OUT
BACK
IMPORTANT: Only plug PoE power to Port 1.
Connecting a PoE power source to the PSE Port (#2) will
cause a major device malfunction and void the warranty.
LED VISUAL CUE
SOLID GREEN
POWER
OFF
SOLID GREEN
LAN
OFF
RSSI1 SOLID RED
RSSI2 SOLID ORANGE
RSSI3 SOLID GREEN
RSSI4 SOLID GREEN
PORT 1 - POE IN
INDICATION
Power is supplied to the unit
No power is supplied to the unit, or the unit is in reset.
LAN Connected
No Connectivity
Weak Connection
Moderate Connection
Solid Connection
Excellent Connection
(Advisable to check Status Page to confirm RSSI is > -55)
NW10
EXCELLENT SIGNAL
PAGE 2
