RS-232 Interface Features — cont.

NAK Character

START
MODE
Sets the NAK character from the set of ASCII charac-
ters or any decimal value from 000 to 255. Pad
entries of less than three digits with zeros, as in
"005". To configure this feature, scan the "START" bar
code above to place the unit in Programming Mode,
then the "Set NAK Character," followed by the digits
from the Alphanumeric table in
Numeric Pad
Exit programming mode by scanning the "END" bar-
code below.
Set NAK
Character
END
Product Reference Guide
BARCODE
representing your desired character.
DEFAULT SETTING FOR THIS FEATURE: 021
Interface Features
Appendix C, Alpha-
3-25
